Toyota 85925-17010 RELAY, IGNITION, NO.1
85925-17010
Part overview:
OEM reference 85925-17010 for RELAY, IGNITION, NO.1.
This page currently lists 27 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 28371 |
| Manufacturer Part Number | 85925-17010 |
| Part Description | RELAY, IGNITION, NO.1 |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 85925-17010 |
| Catalog | 141450 |
| PNC | 28371 |
| PNC Group | RELAY, IGNITION, NO.1 |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| SOLARA | 2002.07 - 2002.12 |
ACV20,MCV20
|
286410 |
| CAMRY (JPP) | 1999.08 - |
MCV20,SXV2#..JPP
|
281460 |
| SOLARA | 1998.06 - 2002.07 |
ACV20,MCV20,SXV20
|
286410 |
| TERCEL | 1998.06 - |
5EFE..EL53
|
141450 |
| PASEO | 1998.06 - |
5EFE..EL54
|
144420 |
| AVALON | 1997.12 - 1999.08 |
MCX10
|
361410 |
| COROLLA NAP/SED | 1997.08 - |
ZZE110
|
155440 |
| SIENNA | 1997.08 - |
MCL10
MCL10..WG
|
622410 |
| LEXUS GS300/400/430 | 1997.08 - |
JZS160,UZS16#
|
332490 |
| CAMRY (JPP) | 1996.08 - 1999.08 |
MCV20,SXV20..JPP
|
281460 |
| LEXUS ES300 | 1996.08 - |
MCV20
|
284460 |
| CAMRY (NAP) | 1996.07 - |
MCV20,SXV20..NAP
|
283460 |
| RAV4 | 1995.11 - |
SXA1#
|
662410 |
| CAMRY (JPP) | 1994.08 - 1994.10 |
1MZFE,5SFE..MCV10,SXV10..JPP
|
281450 |
| CAMRY (NAP) | 1994.08 - 1994.10 |
1MZFE,5SFE..MCV10,SXV10..NAP
|
283450 |
| LEXUS ES300 | 1994.08 - 1994.10 |
1MZFE..MCV10
|
284450 |
| MR2 | 1993.11 - 1995.06 |
SW2#
|
211420 |
| CAMRY (JPP) | 1992.11 - 1994.08 |
5SFE..SXV10..JPP
|
281450 |
| CAMRY (NAP) | 1991.09 - 1994.08 |
5SFE..SXV10..NAP
|
283450 |
| CAMRY (JPP) | 1991.06 - 1992.11 |
5SFE..SXV10..JPP
|
281450 |
| MR2 | 1990.01 - 1995.06 |
SW2#
|
211420 |
| MR2 | 1990.01 - 1993.11 |
3SGTE,5SFE..SW2#
SW2#
|
211420 |
| CELICA | 1989.09 - 1993.09 |
AT180,ST18#
|
252460 |
| LEXUS ES250 | 1989.06 - 1991.07 |
2VZFE..VZV21
|
284440 |
| LEXUS LS400 | 1989.05 - 1994.10 |
UCF10
|
431410 |
| CAMRY (JPP) | 1988.11 - 1991.06 |
2VZFE..VZV21
|
281440 |
| MR2 | 1986.12 - 1989.12 |
AW11
|
211410 |
Related Parts
| Part Number | Reference |
|---|---|
| 28300-10020 | RELAY ASSY, STARTER |
| 81980-02010 | FLASHER ASSY, TURN SIGNAL |
| 81980-0W010 | FLASHER ASSY, TURN SIGNAL |
| 81980-12070 | FLASHER ASSY, TURN SIGNAL |
| 81980-12110 | FLASHER ASSY, TURN SIGNAL |
| 82223-12530 | WIRE, CLUTCH START SWITCH |
| 82223-16030 | WIRE, CLUTCH START SWITCH |
| 82285-16020 | WIRE, ILLUMINATION |
| 82616-20010 | PULLER, FUSE |
| 82641-16030 | RELAY, INTEGRATION NO.1 |
| 82641-16050 | RELAY, INTEGRATION NO.1 |
| 82642-22020 | RELAY, RUNNING LIGHT |
Toyota part number 85925-17010 corresponds to RELAY, IGNITION, NO.1. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
