Toyota 15767-31020 PIPE, OIL COOLER
15767-31020
Part overview:
OEM reference 15767-31020 for PIPE, OIL COOLER.
This page currently lists 15 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 15767 |
| Manufacturer Part Number | 15767-31020 |
| Part Description | PIPE, OIL COOLER |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 15767-31020 |
| Catalog | 286430 |
| PNC | 15767 |
| PNC Group | PIPE, OIL COOLER |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| SIENNA | 2014.09 - 2016.08 |
2GRFE..GSL30;2GRFE..GSL35..LE
TOWING PACKAGE-FOR 3500LBS
|
622430 |
| HIGHLANDER (NAP) | 2014.01 - 2016.11 |
2GRFXE..GVU58
2GRFXE..GVU58..G,M
ECUADOR SPEC
|
526420 |
| HIGHLANDER (NAP) | 2013.12 - 2016.11 |
2GRFE..GSU5#
TOWING PACKAGE-5000LBS
|
526420 |
| LEXUS RX350/450H(NAP | 2012.07 - |
2GRFE..GGL15..NAP..8FC
|
523420 |
| VENZA | 2012.05 - |
2GRFE..GGV1#
TOWING PACKAGE-WITH
|
286430 |
| LEXUS RX350/450H(NAP | 2012.04 - |
2GR#..GGL10,GYL15..NAP;2GRFE..GGL15..NAP..6FC
TOWING PACKAGE-3500LBS
|
523420 |
| LEXUS RX350/450H(JPP | 2012.03 - |
2GR#..GGL1#,GYL15..JPP
TOWING PACKAGE-3500LBS(W/T.CONVERTER)
|
521430 |
| SIENNA | 2011.03 - 2014.09 |
2GRFE..GSL30;2GRFE..GSL35..LE,XLE
TOWING PACKAGE-FOR 3500LBS
|
622430 |
| SIENNA | 2011.03 - 2013.08 |
2GRFE..GSL35..STD
TOWING PACKAGE-FOR 3500LBS
|
622430 |
| VENZA | 2011.03 - 2012.05 |
2GRFE..GGV1#
TOWING PACKAGE-WITH
|
286430 |
| LEXUS RX350/450H(NAP | 2011.03 - 2012.04 |
2GRFE..GGL1#..NAP
TOWING PACKAGE-3500LBS
|
523420 |
| LEXUS RX350/450H(JPP | 2011.03 - 2012.03 |
2GRFE..GGL1#..JPP
TOWING PACKAGE-3500LBS(W/T.CONVERTER)
|
521430 |
| HIGHLANDER (NAP) | 2011.03 - |
2GRFE..GSU4#
TOWING PACKAGE-5000LBS
|
526410 |
| LEXUS RX350/450H(JPP | 2010.12 - 2012.03 |
2GRFXE..GYL15..JPP
TOWING PACKAGE-3500LBS(W/T.CONVERTER)
|
521430 |
| HIGHLANDER (JPP) | 2010.12 - |
2GRFXE..GVU48
ECUADOR SPEC
|
522420 |
Related Parts
| Part Number | Reference |
|---|---|
| 11496-31010 | GASKET, OIL HOLE COVER |
| 15695-31010 | BOLT, OIL COOLER UNION |
| 15695-62030 | BOLT, OIL COOLER UNION |
| 15710-31021 | COOLER ASSY, OIL |
| 15710-36010 | COOLER ASSY, OIL |
| 15725-36010 | GASKET, OIL COOLER COVER |
| 15767-31010 | PIPE, OIL COOLER |
| 15771-31010 | PIPE, OIL, NO.1 |
| 15772-31030 | PIPE, OIL |
| 15781-31010 | BRACKET, OIL COOLER, NO.1 |
| 15785-31010 | GASKET, OIL COOLER |
| 15785-36010 | GASKET, OIL COOLER |
Toyota part number 15767-31020 corresponds to PIPE, OIL COOLER. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
