Toyota 91612-61045 BOLT(FOR TRANSAXLE & ENGINE SETTING)
91612-61045
Part overview:
OEM reference 91612-61045 for BOLT(FOR TRANSAXLE & ENGINE SETTING).
This page currently lists 59 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 30500E |
| Manufacturer Part Number | 91612-61045 |
| Part Description | BOLT(FOR TRANSAXLE & ENGINE SETTING) |
| Condition | New |
| Quantity Per Vehicle | 7 |
| SKU | 91612-61045 |
| Catalog | 112420 |
| PNC | 30500E |
| PNC Group | BOLT(FOR TRANSAXLE & ENGINE SETTING) |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| COROLLA SED (JPP) | 2024.09 - |
ZWE219
*10-1.25PX45-30
|
153260 |
| COROLLA SED (JPP) | 2024.09 - |
ZWE21#
*10-1.25PX45-30
|
153460 |
| COROLLA SED (JPP) | 2022.09 - 2024.09 |
ZWE219
*10-1.25PX45-30
|
153260 |
| COROLLA SED (JPP) | 2022.09 - 2024.09 |
ZWE21#
*10-1.25PX45-30
|
153460 |
| COROLLA (MEXICO) | 2020.07 - 2022.11 |
ZRE212..CVT
(J)
|
152280 |
| COROLLA SED (NAP) | 2020.07 - 2022.11 |
ZRE212..CVT
(J)
|
152480 |
| COROLLA SED (JPP) | 2020.04 - 2022.08 |
ZRE212..CVT
ZWE21#
*10-1.25PX45-30
|
153260 |
| COROLLA SED (JPP) | 2020.04 - 2022.08 |
ZRE212..CVT
ZWE21#
*10-1.25PX45-30
|
153460 |
| COROLLA SED (JPP) | 2020.04 - |
ZRE212..6F
*10-1.25PX45-30
|
153260 |
| COROLLA SED (JPP) | 2020.04 - |
ZRE212..6F
*10-1.25PX45-30
|
153460 |
| C-HR | 2019.09 - |
NGX10,50..CVT
(J)
|
528510 |
| PRIUS PRIME(PHV) | 2019.05 - |
ZVW52
*10-1.25PX45-30
|
224430 |
| COROLLA (MEXICO) | 2019.03 - 2020.07 |
ZRE212..CVT
(J)
|
152280 |
| COROLLA SED (NAP) | 2019.03 - 2020.07 |
ZRE212..CVT
(J)
|
152480 |
| COROLLA SED (JPP) | 2019.01 - 2020.04 |
ZRE212..CVT
ZWE211
ZRE212..6F
*10-1.25PX45-30
|
153260 |
| COROLLA SED (JPP) | 2019.01 - 2020.04 |
ZRE212..CVT
ZWE211
ZRE212..6F
*10-1.25PX45-30
|
153460 |
| PRIUS | 2018.12 - |
ZVW5#
*10-1.25PX45-30
|
222440 |
| YARIS (FRP) | 2017.03 - 2019.07 |
NCP131..5D..4FC;NCP131..3D..4FC..R
NCP131..5F
*10-1.25PX45-30,(J)
|
116430 |
| YARIS (FRP) | 2017.03 - 2018.11 |
NCP131..3D..4FC..S
*10-1.25PX45-30,(J)
|
116430 |
| C-HR | 2016.10 - 2019.09 |
NGX10,50..CVT
ZYX10
(J)
*10-1.25PX45-30,(J)
|
528510 |
| PRIUS PRIME(PHV) | 2016.09 - 2019.04 |
ZVW52
*10-1.25PX45-30
|
224430 |
| COROLLA | 2016.08 - |
ZRE172..6F
*10-1.25PX45-30,(J)
|
152370 |
| COROLLA | 2016.08 - |
ZRE172..6F
*10-1.25PX45-30,(J)
|
152470 |
| PRIUS | 2015.11 - 2018.12 |
ZVW5#
*10-1.25PX45-30
|
222440 |
| SCION IM/IM | 2015.06 - 2018.05 |
ZRE186..CVT
|
165420 |
| PRIUS V | 2014.11 - 2018.11 |
ZVW41
*10-1.25PX45-30
|
225410 |
| YARIS | 2014.09 - 2016.04 |
NCP150..TAIW
*10-1.25PX45-30
|
113320 |
| YARIS (FRP) | 2014.07 - 2017.03 |
NCP131..4FC
NCP131..5F
*10-1.25PX45-30,(J)
|
116430 |
| YARIS/VIOS/LIMO | 2014.04 - 2016.04 |
NCP150..TAIW
*10-1.25PX45-30
|
149330 |
| YARIS | 2014.03 - 2016.06 |
NCP15#..4FC..(GCC,GEN,PH,VN)
*10-1.25PX45-30,(J)
|
113320 |
| LEXUS CT200H | 2013.12 - 2021.08 |
ZWA10
*10-1.25PX45-30
|
232410 |
| COROLLA | 2013.08 - 2016.08 |
ZRE172..6F
*10-1.25PX45-30,(J)
|
152370 |
| COROLLA | 2013.08 - 2016.08 |
ZRE172..6F
*10-1.25PX45-30,(J)
|
152470 |
| YARIS (FRP) | 2013.05 - 2014.07 |
NCP131..4FC
NCP131..5F
*10-1.25PX45-30,(J)
|
116430 |
| YARIS/VIOS/LIMO | 2013.04 - 2016.08 |
NCP151..4FC..B;NCP150..4FC..(GEN,MA)..D;NCP150..4FC..(GCC,GEN,IDN,MA,PH,TH,VN)..(G
,R,V)..B
*10-1.25PX45-30,(J)
|
149330 |
| PRIUS(PLUG-IN HBD) | 2012.01 - 2015.06 |
ZVW35
*10-1.25PX45-30
|
224420 |
| PRIUS | 2011.12 - 2015.11 |
ZVW30
*10-1.25PX45-30
|
222430 |
| PRIUS V | 2011.09 - 2014.11 |
ZVW41
*10-1.25PX45-30
|
225410 |
| YARIS (JPP) | 2011.08 - 2014.07 |
NCP131..4FC
NCP131..5F
*10-1.25PX45-30
|
112430 |
| COROLLA (S.AMERICA) | 2011.03 - 2014.03 |
ZRE142..ATM
ZRE142..MTM
*10-1.25PX45-30
|
157360 |
| LEXUS CT200H | 2010.12 - 2013.12 |
ZWA10
*10-1.25PX45-30
|
232410 |
| COROLLA JPP | 2010.12 - 2013.08 |
ZRE142..JPP
*10-1.25PX45-30
|
151460 |
| PRIUS(PLUG-IN HBD) | 2009.12 - 2010.10 |
ZVW35
*10-1.25PX45-30
|
224410 |
| PRIUS | 2009.04 - 2011.12 |
ZVW30
*10-1.25PX45-30
|
222430 |
| YARIS | 2008.08 - 2011.08 |
NCP91..4FC
NCP91..5F
*10-1.25PX45-30
|
112420 |
| YARIS | 2008.08 - |
NCP93..ATM
NCP93..MTM
*10-1.25PX45-30
|
141470 |
| COROLLA JPP | 2007.12 - 2010.12 |
ZRE142..JPP
*10-1.25PX45-30
|
151460 |
| YARIS | 2007.08 - 2008.08 |
NCP91..4FC
NCP91..5F
*10-1.25PX45-30
|
112420 |
| SCION XD | 2007.06 - 2014.07 |
ZSP110..4FC
ZSP110..5F
*10-1.25PX45-30
|
117420 |
| YARIS | 2006.11 - 2007.08 |
NCP91..5F..CND;NCP91..3D..5F..USA
*10-1.25PX45-30
|
112420 |
| YARIS | 2006.06 - 2008.08 |
NCP93..ATM
*10-1.25PX45-30
|
141470 |
| YARIS | 2006.06 - 2007.08 |
NCP91..4FC
*10-1.25PX45-30
|
112420 |
| YARIS (FRP) | 2006.03 - 2008.11 |
NLP90..FRP
*10-1.25PX45-30
|
116520 |
| YARIS | 2006.03 - 2008.08 |
NCP93..MTM
*10-1.25PX45-30
|
141470 |
| SCION XA | 2006.03 - 2006.12 |
NCP61..4FC
*10-1.25PX45-30
|
117410 |
| SCION XB | 2006.03 - |
NCP31..ATM
NCP31..MTM
*10-1.25PX45-30
|
115410 |
| SCION XA | 2006.03 - |
NCP61..5F
*10-1.25PX45-30
|
117410 |
| LEXUS LS430 | 2000.08 - 2003.07 |
UCF30
*10-1.25PX45-30,NO.1
|
431430 |
| LEXUS LS400 | 1997.07 - |
UCF20
*10-1.25PX45-30
|
431420 |
Related Parts
| Part Number | Reference |
|---|---|
| 33117-52030 | PROTECTOR, AUTOMATIC TRANSMISSION CASE |
| 34365-52012 | RETAINER, OUTER RACE |
| 35012-12010 | HOSE SUB-ASSY, TRANSMISSION BREATHER |
| 35013-52160 | TUBE SUB-ASSY, TRANSMISSION OIL FILLER |
| 35102-52020 | COVER SUB-ASSY, TRANSAXLE REAR |
| 35103-52160 | GAGE SUB-ASSY, TRANSMISSION OIL LEVEL |
| 35104-52031 | CASE SUB-ASSY, AUTOMATIC TRANSAXLE |
| 35104-52032 | CASE SUB-ASSY, AUTOMATIC TRANSAXLE |
| 35106-52020 | PAN SUB-ASSY, AUTOMATIC TRANSAXLE OIL |
| 35145-21010 | GASKET, TRANSAXLE CASE |
| 35149-21010 | GASKET, TRANSAXLE CASE 2ND BRAKE |
| 35159-21010 | GASKET, BRAKE DRUM |
Toyota part number 91612-61045 corresponds to BOLT(FOR TRANSAXLE & ENGINE SETTING). Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
