Toyota 90179-22029 NUT (FOR REAR DRIVE PINION)
90179-22029
Part overview:
OEM reference 90179-22029 for NUT (FOR REAR DRIVE PINION).
This page currently lists 95 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 41204B |
| Manufacturer Part Number | 90179-22029 |
| Part Description | NUT (FOR REAR DRIVE PINION) |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 90179-22029 |
| Catalog | 663410 |
| PNC | 41204B |
| PNC Group | NUT (FOR REAR DRIVE PINION) |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| 4RUNNER | 2024.12 - |
TZNA5#
OD=43
|
6714A0 |
| HILUX (SCB/XTR) | 2024.11 - |
GUN126..LA;GUN135..BZAG;GUN125..AGTP..LA..CBU
GUN126..LA;GUN125..AGTP..LA..CBU
OD=43
OD=43,DIFFERENTIAL LOCK-WITH
|
6723E0 |
| HILUX (DOUBLE CAB) | 2024.11 - |
GUN13#..6F..BZAG;GUN125,135..AGTP..L..LA
GUN125,135..AGTP..L..LA
GUN125..AGTP..6F..S
OD=43
OD=43,DIFFERENTIAL LOCK-WITH
OD=43,DIFFERENTIAL LOCK-WITHOUT
|
6733E0 |
| LEXUS LX SERIES | 2024.11 - |
FJA310,VJA310,VJH310
OD=43
|
792270 |
| LEXUS LX600/700H | 2024.11 - |
VJA310,VJH310
OD=43
|
792470 |
| HILUX (SCB/XTR) | 2024.08 - |
GUN125..LA..IV3;GUN125..THP..LA;GUN135,TGN136..ARL,LA,TH;GUN12#..ARL,BZAG,GCC,GEN,
IDN,MA,TH;GUN11#,136,TGN111,121,126..THP..(ARL,GCC,GEN,LA)
OD=43
|
6723E0 |
| HILUX (DOUBLE CAB) | 2024.08 - |
GUN125..BZAG;GUN126..S..IV3;GUN135..6FC..BZAG;GUN126..H..MHV..IV3;GUN125,135..MAP,
TGN121..5F..(H,S)
THP;GUN125,135..AGTP..S..LA;GUN136,TGN121..6FC..(ARL,BZAG);GUN126..(AGTP,CAMP,INDP
,MAP,MMRP,THP)..CBU;GGN125,GUN120,121,122,136,TGN121,126,136..(AGTP,THP)..(GCC,GEN
,LA,SA,TH)
OD=43
OD=43,SAUDI ARABIA SPEC
|
6733E0 |
| LAND CRUISER | 2024.02 - |
TJH250
OD=43
|
781490 |
| LEXUS GX550 | 2024.02 - |
VJA252
OD=43
|
782420 |
| LAND CRUISER | 2023.09 - 2025.08 |
VDJ79..RHD;VDJL79..LX
|
781370 |
| LAND CRUISER | 2023.09 - 2024.09 |
VDJ79..GCC;VDJL79..STD;VDJ76,78,L76,L78
|
781370 |
| LAND CRUISER | 2023.09 - |
GDJ7#,L7#,GRJ7#,HZJ7#
|
781370 |
| HILUX (DOUBLE CAB) | 2023.08 - 2024.09 |
GUN126..IND,MMR
OD=43
|
6733D0 |
| HILUX (SCB/XTR) | 2023.08 - 2024.08 |
GUN125..MA
OD=43
|
6723D0 |
| HILUX (DOUBLE CAB) | 2023.08 - 2024.08 |
GUN125,126..CAMP,MAP
OD=43
|
6733D0 |
| HILUX (SCB/XTR) | 2023.08 - 2024.07 |
GUN12#,135..THP..(ARL,GCC,GEN,IDN,LA,TH);GUN11#,136,TGN111,121,126..THP..(ARL,GCC,
GEN,LA)
OD=43
|
6723D0 |
| HILUX (DOUBLE CAB) | 2023.08 - 2024.07 |
GUN125,126,135..THP..DCRL;GUN126..MHV..(ARL,GCC,LA);GGN125,GUN120,121,122,136,TGN1
TGN121..5F..(H,S)
21,126,136..THP..(ARL,GCC,GEN,LA,TH)
OD=43
OD=43,SAUDI ARABIA SPEC
|
6733D0 |
| HILUX (SCB/XTR) | 2023.08 - |
GUN122,126,TGN121..PKN
OD=43
|
6723D0 |
| HILUX (DOUBLE CAB) | 2023.08 - |
GUN126..PKN
OD=43
|
6733D0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2023.09 |
GUN126..IND,MMR
OD=43
|
6733C0 |
| HILUX (SCB/XTR) | 2022.08 - 2023.08 |
GUN125..MA
OD=43
|
6723C0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2023.08 |
GUN125,126..MA
OD=43
|
6733C0 |
| HILUX (SCB/XTR) | 2022.08 - 2023.07 |
GUN12#,135..THP..(ARL,GCC,GEN,IDN,LA,TH);GUN11#,136,TGN111,121,126..THP..(ARL,GCC,
GEN,LA)
OD=43
|
6723C0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2023.07 |
GUN125,126,135..THP;GGN125,GUN120,121,122,136,TGN121,126,136..THP..(ARL,GCC,GEN,LA
,TH)
OD=43
|
6733C0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2023.04 |
TGN121..5F..(H,S)
OD=43,SAUDI ARABIA SPEC
|
6733C0 |
| HILUX (SCB/XTR) | 2022.08 - |
GUN122,126,TGN121..PKN
OD=43
|
6723C0 |
| HILUX (DOUBLE CAB) | 2022.08 - |
GUN126..PKN
OD=43
|
6733C0 |
| LEXUS LX SERIES | 2021.12 - 2024.11 |
FJA310,VJA310
OD=43
|
792270 |
| LEXUS LX600/700H | 2021.12 - 2024.11 |
VJA310
OD=43
|
792470 |
| TUNDRA/SEQUOIA | 2021.11 - 2024.08 |
VXKA75..DCB..L
|
841440 |
| TUNDRA/SEQUOIA | 2021.11 - |
VXKA75..CMAX;VXKA75..DCB..S;VXKA76,77,VXKH75,76,85
|
841440 |
| TACOMA | 2021.09 - |
GRN305..DCB..6FC..SR5
OD=43, TRAIL EDITION PACKAGE
|
674470 |
| HILUX (SCB/XTR) | 2021.08 - 2023.01 |
GUN122,126,TGN121..PKN
OD=43
|
6723B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2023.01 |
GUN126..MMR,PKN
OD=43
|
6733B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2022.09 |
GUN126..IND
OD=43
|
6733B0 |
| HILUX (SCB/XTR) | 2021.08 - 2022.08 |
GUN125..MA
OD=43
|
6723B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2022.08 |
GUN125,126..MA
OD=43
|
6733B0 |
| HILUX (SCB/XTR) | 2021.08 - 2022.07 |
GUN12#,135..THP..(ARL,GCC,GEN,IDN,LA,TH);GUN11#,136,TGN111,121,126..THP..(ARL,GCC,
GEN,LA)
OD=43
|
6723B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2022.07 |
GUN125,126,135..THP;GGN125,GUN120,121,122,136,TGN121,126,136..THP..(ARL,GCC,GEN,LA
,TH)
OD=43
|
6733B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2022.03 |
TGN121..5F..GCC
OD=43,SAUDI ARABIA SPEC
|
6733B0 |
| GRNVA/HIACE/MJSTY | 2021.07 - |
GDH322..RHD..P..GEN
OD=43
|
711370 |
| HILUX | 2020.06 - 2023.01 |
GUN120,122..GCC,GEN,TH;GUN125,126,135..MD,MMD,MS,TD,TS,TX;GGN125,GUN112,136,TGN111
,121,126,136..(TD,TS,TX)..(ARL,GCC,GEN,LA)
OD=43
|
6723A0 |
| HILUX | 2020.06 - 2022.01 |
GUN122,126,TGN121..PKN
OD=43
|
6723A0 |
| GRNVA/HIACE/MJSTY | 2020.06 - 2021.06 |
GDH322..RHD..P..GEN
OD=43
|
711370 |
| HILUX | 2020.06 - 2021.03 |
TGN121..TD..5F..GCC
OD=43,SAUDI ARABIA SPEC
|
6723A0 |
| GRNVA/HIACE/MJSTY | 2020.06 - |
GDH322..Q..GEN
OD=43
|
711370 |
| TACOMA | 2019.09 - |
GRN305..6F
GRN305,310,325,330..6FC..SR5
GRN305..DCB..6FC..SR5
OD=43
OD=43,OFF ROAD PACKAGE
OD=43,TRD-PRO PACKAGE
|
674470 |
| 4RUNNER | 2019.08 - |
GRN28#
OD=43
|
671490 |
| LEXUS GX460 | 2019.08 - |
URJ150
OD=43
|
782410 |
| GRNVA/HIACE/MJSTY | 2019.02 - 2025.05 |
GDH306..LHD..G;GDH301,322..GSOB..6F..N;GDH300..RHD..4D..SP..6FC..GEN
OD=43
|
711370 |
| GRNVA/HIACE/MJSTY | 2019.02 - 2025.01 |
GDH320,322,328..AGT,BZ
OD=43
|
711370 |
| GRNVA/HIACE/MJSTY | 2019.02 - 2024.04 |
GDH301..RHD..GSOB..6F;GDH322..RHD..GSOB..6FC..D
OD=43
|
711370 |
| GRNVA/HIACE/MJSTY | 2019.02 - 2023.01 |
GDH321..GEN
OD=43
|
711370 |
| GRNVA/HIACE/MJSTY | 2019.02 - 2020.05 |
GDH322..RHD..(P,Q)..GEN
OD=43
|
711370 |
| GRNVA/HIACE/MJSTY | 2019.02 - |
GDH300..5D;GDH306,321..RHD;GDH301..GSOB..6FC;GDH322..ARL,GCC,NZ;GDH322..RHD..GSOB.
.N;GDH322..LHD..GSOB..6FC;GDH322..GSOB..6F..(D,P);GDH300..4D..SP..(ARL,TH);GDH301.
.LHD..GSOB..6F..D;GDH322..LHD..SG..(P,Q)..GEN;GDH300..RHD..4D..SP..6F..GEN;GDH300,
306..LHD..(SG,SP)..(D,J)..GEN;GDH303,304,320,328,GRH30#,32#..ARL,GCC,GEN,PH,TH,VN;
GDH300,301,322..4D..(PSOB,SG)..(D,N)..(ARL,GEN,NZ,TH)
OD=43
|
711370 |
| TACOMA | 2017.11 - 2019.09 |
GRN305..6F
GRN305,310,325,330..6FC..SR5
GRN305..DCB..6FC..SR5
OD=43
OD=43,OFF ROAD PACKAGE
OD=43,TRD PRO PACKAGE
|
674470 |
| TUNDRA | 2017.08 - 2019.07 |
UPK56;USK56,57..HTWCF
|
841430 |
| SEQUOIA | 2017.08 - 2017.09 |
USK65..HTWCF
OD=43
|
842420 |
| TUNDRA | 2017.08 - |
USK56,57..HTWC
|
841430 |
| SEQUOIA | 2017.08 - |
USK6#..HTWC
USK65..HTWC
OD=43
|
842420 |
| LAND CRUISER | 2016.08 - 2023.09 |
HZJ76,78,79..GEN;GRJ7#,HZJ71,VDJ7#,L7#..CBU,IV
|
781370 |
| TACOMA | 2016.08 - 2017.11 |
GRN305..DCB..6FC..SR5
OD=43,TRD PRO PACKAGE
|
674470 |
| LAND CRUISER | 2016.08 - 2016.12 |
HZJ76,78,79..GCC
|
781370 |
| LEXUS LX570 | 2015.09 - |
URJ201
|
792460 |
| LAND CRUISER | 2015.08 - 2021.04 |
URJ200
|
791460 |
| TACOMA | 2015.08 - 2017.11 |
GRN305,TRN245..5F,6F
GRN305,310,325,330..6FC..SR5
OD=43
OD=43,WITH(*FTP & *EUC:PNC51405A & 51406A)
|
674470 |
| HILUX | 2015.05 - 2021.05 |
TGN136..(TDC,TSC,TXT)..5F;GUN120,122,125,126,13#,KUN125..(MDC,MSC,PDC,PSC,TDC,TSC,
TXT)..(5FC,6F,6FC);GGN12#,GUN112,122,123,KUN126,13#,TGN111,121,126..(PDC,PSC,TDC,T
SC,TXT)..(ARL,GCC,GEN,LA,PKN,VN)
OD=43
|
672390 |
| HILUX | 2015.05 - 2020.06 |
GUN125..ADC..6FC
OD=43
|
672390 |
| HILUX | 2015.05 - 2020.05 |
TGN121..TDC..5F..GCC
OD=43,SAUDI ARABIA SPEC
|
672390 |
| HILUX | 2015.05 - 2019.12 |
TGN121..TDC..5F..GCC
OD=43,SAUDI ARABIA SPEC(EURO4 REGULATION)
|
672390 |
| HILUX | 2015.05 - 2016.03 |
KUN126..ADC..5FC;KUN126..ADC..6F..M;TGN136..(ADC,ASC)..(M,X);GUN125,126,13#,KUN125
,135,TGN126..ADC,ASC
OD=43
|
672390 |
| 4RUNNER | 2013.08 - 2019.08 |
GRN28#
OD=43
|
671490 |
| LEXUS GX460 | 2013.08 - 2019.08 |
URJ150
OD=43
|
782410 |
| TUNDRA | 2013.08 - 2017.08 |
UPK56,USK56,57
|
841430 |
| LEXUS LX570 | 2012.01 - 2015.09 |
URJ201
|
792460 |
| LAND CRUISER | 2012.01 - 2015.08 |
URJ200
|
791460 |
| FJ CRUISER | 2010.11 - 2014.07 |
GSJ1#
OD=43
|
663410 |
| LEXUS GX460 | 2009.11 - 2013.08 |
URJ150
OD=43
|
782410 |
| 4RUNNER | 2009.08 - 2013.08 |
GRN28#
OD=43
|
671490 |
| 4RUNNER | 2009.08 - 2011.08 |
TRN28#
OD=43
|
671490 |
| FJ CRUISER | 2009.08 - 2010.11 |
GSJ1#
OD=43
|
663410 |
| TUNDRA | 2009.04 - 2013.08 |
USK55,56;UPK56,USK57..S
|
841430 |
| TUNDRA | 2009.04 - 2010.05 |
UPK57;UPK55,56..D,L
|
841430 |
| SEQUOIA | 2007.11 - 2017.08 |
USK6#
USK65
OD=43
|
842420 |
| SEQUOIA | 2007.11 - 2012.08 |
UPK6#
UPK65
OD=43
|
842420 |
| LEXUS LX570 | 2007.11 - 2012.01 |
URJ201
|
792460 |
| SEQUOIA | 2007.11 - 2009.04 |
UCK6#
UCK65
OD=43
|
842420 |
| LAND CRUISER | 2007.09 - 2012.01 |
URJ200
|
791460 |
| LAND CRUISER | 2007.01 - 2016.08 |
GRJ71,76,78..LHD;GRJ79,HZJ7#,VDJ7#
|
781370 |
| LAND CRUISER | 2007.01 - 2012.08 |
GRJ71,78..RHD
|
781370 |
| LAND CRUISER | 2007.01 - 2009.07 |
FZJ7#
|
781370 |
| TUNDRA | 2006.11 - 2009.04 |
UCK55,56,57,USK55,56,57
|
841430 |
| LAND CRUISER | 2006.09 - 2007.01 |
FZJ7#,HDJ7#,HZJ7#
|
781330 |
| LAND CRUISER 100 | 2006.09 - |
UZJ100
|
791450 |
| LEXUS LX470 | 2006.09 - |
UZJ100
|
792450 |
Related Parts
| Part Number | Reference |
|---|---|
| 12157-10010 | GASKET (FOR REAR AXLE HOUSING FILLER PLUG) |
| 12157-10010 | GASKET (FOR REAR AXLE HOUSING DRAIN PLUG) |
| 33275-16010 | SEAT, REAR DIFFERENTIAL LOCK SHIFT DETENT BALL SPRING |
| 41039-34060 | GEAR KIT, DIFFERENTIAL, REAR |
| 41039-34080 | GEAR KIT, DIFFERENTIAL, REAR |
| 41101-35150 | CARRIER SUB-ASSY, DIFFERENTIAL, REAR |
| 41101-35170 | CARRIER SUB-ASSY, DIFFERENTIAL, REAR |
| 41101-35180 | CARRIER SUB-ASSY, DIFFERENTIAL, REAR |
| 41101-35190 | CARRIER SUB-ASSY, DIFFERENTIAL, REAR |
| 41102-35010 | CARRIER SUB-ASSY, DIFFERENTIAL W/PIN, REAR |
| 41102-35020 | CARRIER SUB-ASSY, DIFFERENTIAL W/PIN, REAR |
| 41110-35B10 | CARRIER ASSY, DIFFERENTIAL, REAR |
Toyota part number 90179-22029 corresponds to NUT (FOR REAR DRIVE PINION). Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
