Toyota 23217-46090 FILTER, FUEL PUMP
23217-46090
Part overview:
OEM reference 23217-46090 for FILTER, FUEL PUMP.
This page currently lists 14 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 23217A |
| Manufacturer Part Number | 23217-46090 |
| Part Description | FILTER, FUEL PUMP |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 23217-46090 |
| Catalog | 242410 |
| PNC | 23217A |
| PNC Group | FILTER, FUEL PUMP |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| LEXUS SC430 | 2005.08 - |
3UZFE..UZZ40
|
321450 |
| LEXUS IS300 | 2001.07 - |
2JZGE..JCE10
|
242410 |
| LEXUS SC430 | 2001.01 - 2005.08 |
3UZFE..UZZ40
|
321450 |
| SEQUOIA | 2000.09 - 2003.04 |
2UZFE..UCK35,45
(J)
|
842410 |
| LEXUS LS430 | 2000.08 - 2003.07 |
3UZFE..UCF30
|
431430 |
| LEXUS IS300 | 2000.05 - 2001.07 |
2JZGE..JCE10
|
242410 |
| TUNDRA | 1999.02 - 2002.08 |
2UZFE..UCK30,40
|
841420 |
| LEXUS GS300/400/430 | 1997.08 - |
2JZGE..JZS160
1UZFE,3UZFE..UZS16#
|
332490 |
| 4RUNNER | 1995.11 - 2000.08 |
3RZFE..RZN18#
|
671460 |
| 4RUNNER | 1995.11 - |
5VZFE..VZN18#
|
671460 |
| T100 | 1994.08 - |
5VZFE..VCK11,21
|
841410 |
| PREVIA | 1994.01 - 1996.08 |
2TZFE..TCR10,20
|
652440 |
| T100 | 1993.10 - |
3RZFE..RCK10
|
841410 |
| SUPRA | 1993.05 - 1998.08 |
2JZGE..JZA80
|
291430 |
Related Parts
| Part Number | Reference |
|---|---|
| 22030-46220 | BODY ASSY, THROTTLE W/MOTOR |
| 22060-46070 | LEVER ASSY, THROTTLE W/SENSOR |
| 22218-46120 | COVER(FOR THROTTLE BODY) |
| 22267-46030 | BRACKET, THROTTLE BODY |
| 22271-46070 | GASKET, THROTTLE BODY |
| 23020-46030 | REGULATOR ASSY, FUEL PRESSURE W/JET PUMP |
| 23207-46021 | DAMPER ASSY, FUEL PRESSURE PULSATION |
| 23209-46090 | INJECTOR ASSY, FUEL |
| 23221-46120 | PUMP ASSY, FUEL |
| 23229-16010 | CLIP(FOR FUEL PUMP FILTER) |
| 23249-46180 | RUBBER, CUSHION(FOR FUEL PUMP) |
| 23291-62010 | INSULATOR, INJECTOR VIBRATION |
Toyota part number 23217-46090 corresponds to FILTER, FUEL PUMP. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
