Toyota 23217-0C010 FILTER, FUEL PUMP
23217-0C010
Part overview:
OEM reference 23217-0C010 for FILTER, FUEL PUMP.
This page currently lists 28 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 23217D |
| Manufacturer Part Number | 23217-0C010 |
| Part Description | FILTER, FUEL PUMP |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 23217-0C010 |
| Catalog | 282470 |
| PNC | 23217D |
| PNC Group | FILTER, FUEL PUMP |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| AVALON | 2010.03 - |
2GRFE..GSX30
|
361430 |
| LEXUS ES350 | 2009.08 - |
2GRFE..GSV40
|
282480 |
| CAMRY (NAP) | 2009.03 - 2011.09 |
2GRFE..GSV40..NAP
|
283480 |
| CAMRY (JPP) | 2009.01 - 2011.08 |
2GRFE..GSV40..JPP
|
284480 |
| AVALON | 2007.07 - 2010.03 |
2GRFE..GSX30..LIMD,XLS
|
361430 |
| AVALON | 2007.07 - |
2GRFE..GSX30..XL
|
361430 |
| SOLARA | 2006.05 - 2008.08 |
3MZFE..MCV31..CP
|
286420 |
| SOLARA | 2006.05 - |
3MZFE..MCV31..CVT
|
286420 |
| LEXUS ES350 | 2006.03 - 2009.08 |
2GRFE..GSV40
|
282480 |
| CAMRY (NAP) | 2006.02 - 2009.03 |
2GRFE..GSV40..NAP
|
283480 |
| CAMRY (JPP) | 2006.01 - 2009.01 |
2GRFE..GSV40..JPP
|
284480 |
| AVALON | 2005.01 - 2007.07 |
2GRFE..GSX30
|
361430 |
| LEXUS ES300/330 | 2004.06 - 2006.03 |
3MZFE..MCV31
|
282470 |
| CAMRY (NAP) | 2004.06 - |
2AZFE,1MZFE,3MZFE..ACV30,MCV3#..NAP
|
283470 |
| CAMRY (JPP) | 2004.06 - |
2AZFE,1MZFE,3MZFE..ACV30,MCV3#..JPP
|
284470 |
| SOLARA | 2003.07 - 2006.05 |
2AZFE,3MZFE..ACV30,MCV31..5F,5FC
|
286420 |
| SOLARA | 2003.07 - 2005.03 |
2AZFE..ACV30..4FC
|
286420 |
| AVALON | 2002.06 - 2005.01 |
1MZFE..MCX20
|
361420 |
| CAMRY (NAP) | 2001.07 - 2004.06 |
2AZFE,1MZFE,3MZFE..ACV30,MCV3#..NAP
|
283470 |
| CAMRY (JPP) | 2001.07 - 2004.06 |
2AZFE,3MZFE..ACV30,MCV31..JPP;1MZFE..MCV30..JPP..(LE,XLE)..5FC
|
284470 |
| LEXUS ES300/330 | 2001.07 - 2004.06 |
1MZFE,3MZFE..MCV3#
|
282470 |
| CAMRY (JPP) | 2001.07 - 2003.07 |
1MZFE..MCV30..JPP..SE..5FC
|
284470 |
| CAMRY (JPP) | 2001.07 - 2003.01 |
1MZFE..MCV30..JPP
|
284470 |
| AVALON | 2001.07 - 2002.06 |
1MZFE..MCX20
|
361420 |
| TACOMA | 2000.09 - |
3RZFE..RZN161,171
5VZFE..VZN170
|
674460 |
| TACOMA | 2000.09 - |
2RZFE,3RZFE..RZN140,150,19#
5VZFE..VZN150,195
|
675460 |
| TACOMA | 1995.01 - 2000.09 |
3RZFE..RZN161,171
5VZFE..VZN160,170
|
674460 |
| TACOMA | 1995.01 - 2000.09 |
5VZFE..VZN150,195
2RZFE,3RZFE..RZN140,150,19#
|
675460 |
Related Parts
| Part Number | Reference |
|---|---|
| 23020-20010 | REGULATOR ASSY, FUEL PRESSURE |
| 23219-03010 | CLIP(FOR FUEL PUMP FILTER) |
| 23221-0A040 | PUMP, FUEL |
| 23249-46180 | RUBBER, CUSHION(FOR FUEL PUMP) |
| 23280-20060 | REGULATOR ASSY, FUEL PRESSURE |
| 23300-21010 | FILTER ASSY, FUEL |
| 77001-33110 | TANK ASSY, FUEL |
| 77001-33190 | TANK ASSY, FUEL |
| 77024-33030 | PLATE SUB-ASSY, FUEL SUCTION |
| 77024-33050 | PLATE SUB-ASSY, FUEL SUCTION |
| 77030-33050 | LOCK SUB-ASSY, FUEL FILLER OPENING LID |
| 77168-33050 | PLATE, FUEL TANK VENT TUBE SET |
Toyota part number 23217-0C010 corresponds to FILTER, FUEL PUMP. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
