Toyota 16100-19365 PUMP ASSY, ENGINE WATER
16100-19365
Part overview:
OEM reference 16100-19365 for PUMP ASSY, ENGINE WATER.
This page currently lists 19 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 16100 |
| Manufacturer Part Number | 16100-19365 |
| Part Description | PUMP ASSY, ENGINE WATER |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 16100-19365 |
| Catalog | 672390 |
| PNC | 16100 |
| PNC Group | PUMP ASSY, ENGINE WATER |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| HILUX (SCB/XTR) | 2022.08 - 2023.07 |
2GDFTV..GUN120,125,135..GCC,TH
(J)
|
6723C0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2023.07 |
2GDFTV..GUN125..LHD..S..GEN;2GDFTV..GUN120,125,135..GCC,PH,TH
2GDFTV..GUN125..LHD..L..GEN
(J)
MOROCCO SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),(J)
|
6733C0 |
| HILUX (SCB/XTR) | 2022.08 - 2023.05 |
2GDFTV..GUN125..GCC
GCC SPEC EURO4 2022MY,(J)
|
6723C0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2023.05 |
2GDFTV..GUN125..6F..(H,L)..GCC
2GDFTV..GUN125..6F..L..GCC;2GDFTV..GUN125..6FC..S..GCC
2GDFTV..GUN125..LHD..S..GEN
2GDFTV..GUN125..H..GCC
2GDFTV..GUN125..H..GCC;2GDFTV..GUN125..6F..L..GCC
2GDFTV..GUN125..6F..H..GCC
2GDFTV..GUN125..6F..S..GCC;2GDFTV..GUN125..6FC..(L,S)..GCC
EGYPT SPEC&EXHAUST EMISSION CONTROL-WITHOUT,(J)
UAE SPEC,(J)
(J)
SUDAN SPEC&EXHAUST EMISSION CONTROL-WITHOUT,(J)
JORDAN SPEC,(J)
IRAQ SPEC&EXHAUST EMISSION CONTROL-WITHOUT,(J)
AZERBAIJAN SPEC,(J)
AFRICA SPEC&EXHAUST EMISSION CONTROL-WITHOUT,(J)
SYRIA SPEC&EXHAUST EMISSION CONTROL-WITHOUT,(J)
ASIA COLD COUNTRY SPEC&EXHAUST EMISSION CONTROL-WITHOUT,(J)
ASEAN GENERAL SPEC&EXHAUST EMISSION CONTROL-WITHOUT,(J)
OCEANIA GENERAL SPEC&EXHAUST EMISSION CONTROL-WITHOUT,(J)
CAMBODIA SPEC,(J)
GCC SPEC EURO4 2022MY,(J)
GCC SPEC EURO4 2022MY&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS),(J)
SUDAN SPEC&EXHAUST EMISSION CONTROL-EURO 2 WITHOUT(ON BOARD DIAGNOSIS),(J)
|
6733C0 |
| HILUX (SCB/XTR) | 2021.08 - 2022.07 |
2GDFTV..GUN120,135..TH;2GDFTV..GUN125..THP..(GCC,LA,TH)
(J)
|
6723B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2022.07 |
2GDFTV..GUN125..LHD..S..GEN;2GDFTV..GUN120,125,135..THP..(GCC,LA,PH,TH,VN)
2GDFTV..GUN125..LHD..L..GEN
(J)
MOROCCO SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),(J)
|
6733B0 |
| HILUX | 2020.06 - 2021.08 |
2GDFTV..GUN125..LHD..TD..S..GEN;2GDFTV..GUN135..(TD,TX)..(LA,PH,TH,VN);2GDFTV..GUN
2GDFTV..GUN125..LHD..L..GEN
120,125..(TD,TS,TX)..(GCC,LA,PH,TH,VN)
(J)
MOROCCO SPEC&EXHAUST EMISSION CONTROL-EURO 4, WITH(ON BOARD DIAGNOSIS),(J)
|
6723A0 |
| HILUX | 2018.09 - 2020.10 |
2GDFTV..GUN125..PH;2GDFTV..GUN125..6FC..LA;2GDFTV..GUN135..(M,S)..(PH,VN)
2GDFTV..GUN125..ASC..LA
(J)
PERU SPEC,(J)
|
672390 |
| HILUX | 2018.06 - 2020.10 |
2GDFTV..GUN125..GCC
(J)
|
672390 |
| HILUX | 2018.06 - 2018.09 |
2GDFTV..GUN125..RHD..TDC..6F..S..GEN
EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),(J)
|
672390 |
| HILUX | 2017.10 - 2018.09 |
2GDFTV..GUN125..LHD..SSC..S;2GDFTV..GUN125..LHD..SDC..(M,X)
1GDFTV..GUN126..ADC..6F..(M,S)..LA
(J)
BOLIVIA URUGUAY SPEC,(J)
|
672390 |
| HILUX | 2017.08 - 2018.09 |
2GDFTV..GUN125..LHD..TDC..M..GEN
1GDFTV..GUN136..LA;1GDFTV..GUN126..6F..X..LA;2GDFTV..GUN135..(ASC,TSC)..LA;1GDFTV.
2GDFTV..GUN125..TXT..S..GEN;2GDFTV..GUN125..LHD..L..GEN;2GDFTV..GUN125..TSC..6F..L
.GUN126..TDC..6F..(M,S)..LA
..GEN;2GDFTV..GUN125..RHD..TDC..(H,M)..GEN
(J)
BOLIVIA URUGUAY SPEC,(J)
EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),(J)
|
672390 |
| HILUX | 2017.08 - 2018.06 |
2GDFTV..GUN125..TSC..GCC;2GDFTV..GUN125..6FC..L..GCC
2GDFTV..GUN125..TDC..6F..(L,M)..GCC
QATAR SPEC(EURO 4 REGULATION),(J)
JORDAN SPEC,(J)
GCC SPEC(EURO 4 REGULATION),(J)
IRAQ SPEC,(J)
|
672390 |
| HILUX | 2016.08 - 2017.08 |
2GDFTV..GUN125..M..GEN
AZERBAIJAN SPEC(EURO 4 REGULATION),(J)
|
672390 |
| HILUX | 2015.11 - 2018.08 |
1GDFTV..GUN126,136..6F..HDCR..BZAGT
ARGENTINA SPEC(EURO 4 REGULATION),(J)
|
672390 |
| HILUX | 2015.05 - 2020.10 |
2GDFTV..GUN120;2GDFTV..GUN135..6F..VN;2GDFTV..GUN125,135..BZAGT..IV3;2GDFTV..GUN12
5..LHD..TDC..(S,X)..GEN;2GDFTV..GUN135..(ADC,TDC,TXT)..(LA,TH);2GDFTV..GUN125..(TD
C,TSC)..6F..(LA,TH,VN);2GDFTV..GUN125..(ADC,TXT)..6F..(ARL,LA,TH)
(J)
|
672390 |
| HILUX | 2015.05 - 2018.09 |
2GDFTV..GUN125..ASC..CBU;2GDFTV..GUN125..RHD..S..SA;1GDFTV..GUN126,136..6F..M..SA;
1GDFTV..GUN126..6F..M..LA;1GDFTV..GUN126..TDC..6F..X
2GDFTV..GUN135..X..BZAGT..CBU;2GDFTV..GUN135..(L,S)..(BZAGT,SA);2GDFTV..GUN125..RH
D..TDC..6F..L..GEN;2GDFTV..GUN125..(ADC,TDC,TSC)..6F..(ARL,BZAGT)
(J)
COLOMBIA SPEC,(J)
|
672390 |
| HILUX | 2015.05 - 2018.06 |
2GDFTV..GUN125..TDC..(M,S)..GCC;2GDFTV..GUN125..TDC..6F..L..GCC
2GDFTV..GUN125..GCC
QATAR SPEC(EURO 4 REGULATION),(J)
SAUDI ARABIA SPEC(EURO4 REGULATION),(J)
GCC SPEC(EURO 4 REGULATION),(J)
|
672390 |
| HILUX | 2015.05 - 2017.08 |
2GDFTV..GUN135..GEN
(J)
|
672390 |
Related Parts
| Part Number | Reference |
|---|---|
| 16100-09261 | PUMP ASSY, ENGINE WATER |
| 16100-09460 | PUMP ASSY, ENGINE WATER |
| 16100-09710 | PUMP ASSY, ENGINE WATER |
| 16100-09711 | PUMP ASSY, ENGINE WATER |
| 16100-39406 | PUMP ASSY, ENGINE WATER |
| 16100-59257 | PUMP ASSY, ENGINE WATER |
| 16124-0C010 | GASKET, WATER PUMP COVER |
| 16124-31070 | GASKET, WATER PUMP COVER |
| 16171-75020 | SEAT, WATER PUMP PULLEY |
| 16193-31080 | BOLT(FOR WATER PUMP COVER) |
| 16210-0C010 | COUPLING ASSY, FLUID |
| 16210-0E010 | COUPLING ASSY, FLUID |
Toyota part number 16100-19365 corresponds to PUMP ASSY, ENGINE WATER. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
