Toyota G9010-78030 RADIATOR ASSY
G9010-78030
Part overview:
OEM reference G9010-78030 for RADIATOR ASSY.
This page currently lists 4 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | G9010A |
| Manufacturer Part Number | G9010-78030 |
| Part Description | RADIATOR ASSY |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | G9010-78030 |
| Catalog | 527420 |
| PNC | G9010A |
| PNC Group | RADIATOR ASSY |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| LEXUS NX SERIES(JPP) | 2024.04 - |
AAZH2#
|
527420 |
| LEXUS NX SERIES(TMMC | 2024.04 - |
AAZH25
|
52E420 |
| LEXUS NX SERIES(TMMC | 2022.03 - 2024.04 |
AAZH25
TOWING PACKAGE-2000 LBS&RADIATOR-699*453*27 FP2.5
|
52E420 |
| LEXUS NX SERIES(JPP) | 2021.11 - 2024.03 |
AAZH26
AAZH25
TOWING PACKAGE-2000 LBS&RADIATOR-699*453*27 FP2.5
|
527420 |
Related Parts
| Part Number | Reference |
|---|---|
| 16407-64010 | COCK SUB-ASSY, RADIATOR DRAIN |
| 16475-28140 | CAP, RESERVE TANK |
| G9040-42010 | INVERTER WATER PUMP ASSY(W/MOTOR) |
| G9040-42020 | INVERTER WATER PUMP ASSY(W/MOTOR) |
| G9040-48050 | INVERTER WATER PUMP ASSY(W/MOTOR) |
| G9040-48060 | INVERTER WATER PUMP ASSY(W/MOTOR) |
| G910G-42010 | Toyota Genuine Part |
| G9141-42010 | BRACKET SUB-ASSY, HV WATER PUMP |
| G9141-78010 | BRACKET SUB-ASSY, HV WATER PUMP |
| G91H2-42010 | BRACKET, INVERTER RESERVE TANK, NO.1 |
| G9225-42020 | HOSE, INVERTER COOLING, NO.1 |
| G9226-42010 | HOSE, INVERTER COOLING, NO.2 |
Toyota part number G9010-78030 corresponds to RADIATOR ASSY. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
