Toyota 90910-12086 VALVE ASSY, VACUUM SWITCHING
90910-12086
Part overview:
OEM reference 90910-12086 for VALVE ASSY, VACUUM SWITCHING.
This page currently lists 7 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 17650 |
| Manufacturer Part Number | 90910-12086 |
| Part Description | VALVE ASSY, VACUUM SWITCHING |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 90910-12086 |
| Catalog | 671450 |
| PNC | 17650 |
| PNC Group | VALVE ASSY, VACUUM SWITCHING |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| 4-RUNNER TRUCK (JPP) | 1992.08 - 1995.11 |
22RE..RN101,110,130..USA
CALIFORNIA SPEC,NO.3
|
671450 |
| 4-RUNNER TRUCK (NAP) | 1992.02 - 1995.01 |
22RE..RN101,110
CALIFORNIA SPEC,NO.3
|
674450 |
| 4-RUNNER TRUCK (NAP) | 1991.09 - 1995.01 |
22RE..RN80,90
CALIFORNIA SPEC,NO.3
|
675450 |
| 4-RUNNER TRUCK (JPP) | 1989.08 - 1990.08 |
22RE..RN80..STD
NO.3
|
672450 |
| 4-RUNNER TRUCK (JPP) | 1989.05 - 1995.01 |
22RE..RN8#,90..(4HC,5F)..USA
CALIFORNIA SPEC,NO.3
|
672450 |
| 4-RUNNER TRUCK (JPP) | 1988.08 - 1992.08 |
22RE..RN10#,110..USA
CALIFORNIA SPEC,NO.3
|
671450 |
| 4-RUNNER TRUCK (JPP) | 1988.08 - 1989.05 |
22RE..RN120,8#,90..USA
CALIFORNIA SPEC,NO.3
|
672450 |
Related Parts
| Part Number | Reference |
|---|---|
| 17303-35250 | PIPE SUB-ASSY, AIR, NO.1 |
| 17303-35260 | PIPE SUB-ASSY, AIR, NO.1 |
| 17341-35180 | HOSE, NO.1(FOR IDLE-UP) |
| 17341-65020 | HOSE, NO.1(FOR IDLE-UP) |
| 17342-35050 | HOSE, NO.1(FOR IDLE-UP) |
| 17342-35050 | HOSE, NO.2(FOR IDLE-UP) |
| 17360-65021 | TUBE ASSY, AIR |
| 17360-65050 | TUBE ASSY, AIR |
| 17630-16040 | VALVE ASSY, AIR CONTROL |
| 17630-28010 | VALVE ASSY, AIR CONTROL |
| 25701-65020 | VALVE SET, EMISSION CONTROL |
| 25701-65021 | VALVE SET, EMISSION CONTROL |
Toyota part number 90910-12086 corresponds to VALVE ASSY, VACUUM SWITCHING. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
