Toyota 90445-10022 HOSE, NO.2(FOR IDLE-UP)
90445-10022
Part overview:
OEM reference 90445-10022 for HOSE, NO.2(FOR IDLE-UP).
This page currently lists 5 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 17342B |
| Manufacturer Part Number | 90445-10022 |
| Part Description | HOSE, NO.2(FOR IDLE-UP) |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 90445-10022 |
| Catalog | 291410 |
| PNC | 17342B |
| PNC Group | HOSE, NO.2(FOR IDLE-UP) |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| SUPRA | 1990.08 - 1993.05 |
7MG#..MA70
7MGTE..MA70
|
291420 |
| SUPRA | 1989.08 - 1990.08 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA
7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA
|
291420 |
| SUPRA | 1988.08 - 1989.08 |
7MG#..MA70
7MGTE..MA70
|
291420 |
| SUPRA | 1986.08 - 1988.08 |
7MGTE..MA70
|
291410 |
| SUPRA | 1986.01 - 1988.08 |
7MG#..MA70
|
291410 |
Related Parts
| Part Number | Reference |
|---|---|
| 17303-42020 | PIPE SUB-ASSY, AIR, NO.1 |
| 17630-70010 | VALVE ASSY, AIR CONTROL |
| 23881-42010 | BRACKET, VACUUM CONTROL VALVE SET |
| 25706-42010 | PIPE SUB-ASSY, VACUUM TRANSMITTING, NO.1 |
| 25706-42011 | PIPE SUB-ASSY, VACUUM TRANSMITTING, NO.1 |
| 25706-42020 | PIPE SUB-ASSY, VACUUM TRANSMITTING, NO.1 |
| 25706-42021 | PIPE SUB-ASSY, VACUUM TRANSMITTING, NO.1 |
| 25707-42010 | PIPE SUB-ASSY, VACUUM TRANSMITTING, NO.2 |
| 25719-42010 | TANK, VACUUM SURGE |
| 25804-42010 | VALVE SET, VACUUM CONTROL |
| 25860-42010 | VALVE ASSY, VACUUM SWITCHING, NO.1 |
| 25860-42020 | VALVE ASSY, VACUUM SWITCHING, NO.1 |
Toyota part number 90445-10022 corresponds to HOSE, NO.2(FOR IDLE-UP). Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
