Toyota 90116-08376 BOLT, STUD(FOR TIMING GEAR COVER)
90116-08376
Part overview:
OEM reference 90116-08376 for BOLT, STUD(FOR TIMING GEAR COVER).
This page currently lists 16 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 11302H |
| Manufacturer Part Number | 90116-08376 |
| Part Description | BOLT, STUD(FOR TIMING GEAR COVER) |
| Condition | New |
| Quantity Per Vehicle | 2 |
| SKU | 90116-08376 |
| Catalog | 672370 |
| PNC | 11302H |
| PNC Group | BOLT, STUD(FOR TIMING GEAR COVER) |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| HILUX | 2008.08 - 2009.08 |
1KDFTV,2KDFTV..KUN1#,2#,3#..(DCB,SCB,SMT,XTR)..(ANCOM,GCC,GEN,IDN,LA,MA,PHL,TH)
2KDFTV..KUN25,35..THDCB
*130
ECUADOR & COLOMBIA SPEC,*130
|
672370 |
| HIACE | 2007.09 - 2009.08 |
2KDFTV..KDH202..TH
WITHOUT(CKD PACKAGE),ENGINE NO.=9XXXXXX
|
711350 |
| HILUX | 2007.08 - 2008.08 |
2KDFTV..KUN25,35..THDCB
ECUADOR OR COLOMBIA SPEC,*130
|
672370 |
| HIACE | 2006.02 - 2009.08 |
2KDFTV..KDH200..TH
CKD PACKAGE(THAILAND),ENGINE NO.=9XXXXXX
|
711350 |
| HIACE | 2006.02 - 2006.10 |
2KDFTV..KDH200..RHD..4D..5F..GEN
2KDFTV..KDH20#..RHD..SRF..4D..(03S,12S)..5F..GEN
CKD PACKAGE(MALAYSIA),ENGINE NO.=9XXXXXX
CKD PACKAGE(THAILAND),ENGINE NO.=9XXXXXX
|
711350 |
| HIACE | 2005.12 - 2007.09 |
2KDFTV..KDH212..LHD..STD..GEN
VIETNAM SPEC,ENGINE NO.=9XXXXXX
|
711350 |
| HIACE | 2005.12 - 2006.05 |
2KDFTV..KDH212..LHD..STD..GEN
*107
|
711350 |
| HIACE | 2005.08 - 2009.08 |
2KDFTV..KDH202..MA,TH;2KDFTV..KDH202..HRF..GEN;2KDFTV..KDH200,212..MA,VN
ENGINE NO.=9XXXXXX
|
711350 |
| HIACE | 2005.08 - 2005.12 |
2KDFTV..KDH212..STD
ENGINE NO.=9XXXXXX
|
711350 |
| HILUX | 2005.07 - 2006.08 |
1KDFTV,2KDFTV..KUN1#,2#,3#..ARL,GCC,GEN,MA,PHL,SA,TH
|
672370 |
| HILUX | 2005.07 - 2006.05 |
1KDFTV,2KDFTV..KUN2#,3#..ANCOM,LA
|
672370 |
| HIACE | 2005.01 - 2006.05 |
2KDFTV..KDH212..RHD;2KDFTV..KDH212..GCC;2KDFTV..KDH200,22#..ARL,GCC,GEN;2KDFTV..KD
2KDFTV..KDH200..RHD..4D..5F..GEN
H202,212..(SMRF,SRF)..(11S,12S,15S)..(GCC,GEN)
*107
MALAYSIA SPEC,*107
|
711350 |
| HILUX | 2004.08 - 2008.12 |
2KDFTV..KUN25..SCB..MA;2KDFTV..KUN25..(DCB,XTR)..SR;2KDFTV..KUN25..(DCB,SCB)..(ANC
OM,GCC,GEN,LA);1KDFTV,2KDFTV..KUN15,26..(DCB,SCB,XTR)..(GCC,GEN,LA,PHL,TH);1KDFTV,
2KDFTV..KUN10,16,3#..(DCB,SCB,XTR)..(ANCOM,GCC,LA,TH)
*130
|
672370 |
| HILUX | 2004.08 - 2007.10 |
1KDFTV,2KDFTV..KUN15,2#,3#..SA
*130
|
672370 |
| HILUX | 2004.08 - 2006.08 |
1KDFTV..KUN16,26..ARL
*130
|
672370 |
| LAND CRUISER | 1993.05 - 1996.04 |
1KZT..KZJ7#
|
781330 |
Related Parts
| Part Number | Reference |
|---|---|
| 11310-0C010 | COVER SUB-ASSY, TIMING CHAIN OR BELT |
| 11310-0C020 | COVER SUB-ASSY, TIMING CHAIN OR BELT |
| 11310-0C021 | COVER SUB-ASSY, TIMING CHAIN OR BELT |
| 11310-31013 | COVER SUB-ASSY, TIMING CHAIN OR BELT |
| 11310-75061 | COVER SUB-ASSY, TIMING CHAIN OR BELT |
| 11310-75062 | COVER SUB-ASSY, TIMING CHAIN OR BELT |
| 11310-75064 | COVER SUB-ASSY, TIMING CHAIN OR BELT |
| 11310-75070 | COVER SUB-ASSY, TIMING CHAIN OR BELT |
| 11310-75071 | COVER SUB-ASSY, TIMING CHAIN OR BELT |
| 11310-75073 | COVER SUB-ASSY, TIMING CHAIN OR BELT |
| 11311-54052 | CASE SUB-ASSY, TIMING GEAR |
| 11312-54040 | GASKET, FRONT END PLATE |
Toyota part number 90116-08376 corresponds to BOLT, STUD(FOR TIMING GEAR COVER). Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
