Toyota 90043-41041 PLUG, OVERFLOW(CVT)
90043-41041
Part overview:
OEM reference 90043-41041 for PLUG, OVERFLOW(CVT).
This page currently lists 14 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 35125F |
| Manufacturer Part Number | 90043-41041 |
| Part Description | PLUG, OVERFLOW(CVT) |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 90043-41041 |
| Catalog | 106310 |
| PNC | 35125F |
| PNC Group | PLUG, OVERFLOW(CVT) |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| AVANZA/VELOZ | 2021.11 - |
W100,101..CVT
|
613230 |
| RAIZE | 2021.04 - 2026.08 |
A251..L..GCC;A25#..CVT..(V,X)
|
106310 |
| AVANZA | 2019.01 - 2021.10 |
F65#..4AT..(MID,SPO)..IDN
|
613220 |
| AVANZA | 2019.01 - |
F653..4AT..STD;F653..MID..GEN;F654..4AT..MID..GCC;F654..4AT..(SPO,STD)..(GCC,MA,PH
L,SA);F654..4AT..(MID,STD)..(GEN,MXC,PHL,TH)
|
613220 |
| AVANZA | 2015.07 - 2019.04 |
F653,654..4AT
|
613220 |
| AVANZA | 2011.11 - 2015.08 |
F651,652..4AT..(GCC,GEN,MA,MXC,PHL,SA,TH)
|
613220 |
| AVANZA | 2011.11 - 2015.07 |
F65#..4AT..IDN
|
613220 |
| RUSH | 2008.11 - |
J200,210..E4AT
|
661340 |
| AVANZA | 2006.08 - 2009.11 |
F601..4AT
|
613210 |
| AVANZA | 2006.08 - 2008.04 |
K3VE,3SZVE..F60#
|
613210 |
| AVANZA | 2006.08 - |
F602..4AT;F601..4AT..IDN
|
613210 |
| AVANZA | 2006.05 - 2006.08 |
F601..4AT
NO.3
|
613210 |
| AVANZA | 2004.04 - 2006.05 |
F601..4AT
(J),NO.2
|
613210 |
| AVANZA | 2003.12 - 2006.08 |
K3#..F601
|
613210 |
Related Parts
| Part Number | Reference |
|---|---|
| 30400-B2A60 | TRANSAXLE ASSY, CONTINUOUSLY VARIABLE |
| 30400-B2C20 | TRANSAXLE ASSY, CONTINUOUSLY VARIABLE |
| 30400-BZ060 | TRANSAXLE ASSY, CONTINUOUSLY VARIABLE |
| 30400-BZ080 | TRANSAXLE ASSY, CONTINUOUSLY VARIABLE |
| 33449-B2010 | MAGNET, OIL CLEANER(CVT) |
| 35103-B2070 | GAGE SUB-ASSY, TRANSMISSION OIL LEVEL |
| 35103-BZ060 | GAGE SUB-ASSY, TRANSMISSION OIL LEVEL |
| 35145-B2011 | GASKET, TRANSAXLE CASE |
| 35145-BZ010 | GASKET, TRANSAXLE CASE |
| 35160-B2040 | PAN SUB-ASSY, TRANSAXLE OIL(CVT) |
| 35160-BZ030 | PAN SUB-ASSY, TRANSAXLE OIL(CVT) |
| 35168-B2030 | GASKET, TRANSAXLE OIL PAN(CVT) |
Toyota part number 90043-41041 corresponds to PLUG, OVERFLOW(CVT). Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
