Toyota 35106-08010 PAN SUB-ASSY, AUTOMATIC TRANSAXLE OIL
35106-08010
Part overview:
OEM reference 35106-08010 for PAN SUB-ASSY, AUTOMATIC TRANSAXLE OIL.
This page currently lists 13 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 35106D |
| Manufacturer Part Number | 35106-08010 |
| Part Description | PAN SUB-ASSY, AUTOMATIC TRANSAXLE OIL |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 35106-08010 |
| Catalog | 283470 |
| PNC | 35106D |
| PNC Group | PAN SUB-ASSY, AUTOMATIC TRANSAXLE OIL |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| HIGHLANDER (JPP) | 2008.01 - |
GSU4#
(L)
|
522420 |
| SIENNA | 2006.12 - |
GSL2#
(L)
|
622420 |
| SOLARA | 2006.05 - 2008.08 |
MCV31..CP
(L)
|
286420 |
| SOLARA | 2006.05 - |
MCV31..CVT
(L)
|
286420 |
| HIGHLANDER | 2006.02 - |
MCU2#
(L)
|
522410 |
| LEXUS RX330/350(NAP) | 2006.02 - |
GSU3#..NAP
(L)
|
523410 |
| SIENNA | 2005.09 - 2006.12 |
MCL2#
(L)
|
622420 |
| AVALON | 2005.01 - 2007.07 |
GSX30
(L)
|
361430 |
| CAMRY (NAP) | 2004.06 - 2006.02 |
MCV3#..NAP
(L)
|
283470 |
| LEXUS RX330/350(NAP) | 2003.09 - 2006.02 |
MCU3#..NAP
(L)
|
523410 |
| SOLARA | 2003.07 - 2006.05 |
MCV31
(L)
|
286420 |
| SIENNA | 2003.01 - 2005.09 |
MCL2#
(L)
|
622420 |
| CAMRY (NAP) | 2003.01 - 2004.06 |
MCV31..NAP;MCV30..NAP..(LE,XLE)
MCV30..NAP..SE
(L)
|
283470 |
Related Parts
| Part Number | Reference |
|---|---|
| 33117-21010 | PROTECTOR, AUTOMATIC TRANSMISSION CASE |
| 33403-20230 | COVER SUB-ASSY, SPEEDOMETER DRIVEN HOLE (ATM) |
| 33403-33040 | COVER SUB-ASSY, SPEEDOMETER DRIVEN HOLE (ATM) |
| 35013-06060 | TUBE SUB-ASSY, TRANSMISSION OIL FILLER |
| 35013-06070 | TUBE SUB-ASSY, TRANSMISSION OIL FILLER |
| 35013-06131 | TUBE SUB-ASSY, TRANSMISSION OIL FILLER |
| 35102-06010 | COVER SUB-ASSY, TRANSAXLE REAR |
| 35102-06020 | COVER SUB-ASSY, TRANSAXLE REAR |
| 35102-08010 | COVER SUB-ASSY, TRANSAXLE REAR |
| 35102-33010 | COVER SUB-ASSY, TRANSAXLE REAR |
| 35102-33020 | COVER SUB-ASSY, TRANSAXLE REAR |
| 35102-33030 | COVER SUB-ASSY, TRANSAXLE REAR |
Toyota part number 35106-08010 corresponds to PAN SUB-ASSY, AUTOMATIC TRANSAXLE OIL. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
