Toyota 27330-0M100 ROTOR ASSY, ALTERNATOR
27330-0M100
Part overview:
OEM reference 27330-0M100 for ROTOR ASSY, ALTERNATOR.
This page currently lists 62 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 27330 |
| Manufacturer Part Number | 27330-0M100 |
| Part Description | ROTOR ASSY, ALTERNATOR |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 27330-0M100 |
| Catalog | 113320 |
| PNC | 27330 |
| PNC Group | ROTOR ASSY, ALTERNATOR |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| HILUX (DOUBLE CAB) | 2024.12 - |
1GDFTV..GUN126..IND
|
6733E0 |
| HILUX (DOUBLE CAB) | 2024.08 - 2024.11 |
2TRFE..TGN121..5F..ARL
|
6733E0 |
| HILUX (SCB/XTR) | 2024.08 - |
1TRFE,2TRFE..TGN11#,12#..ARL,GCC,GEN;1GDFTV,2GDFTV..GUN112,12#,13#..GEN,IDN,KEN,MA
,PH,SA,TH
|
6723E0 |
| HILUX (DOUBLE CAB) | 2024.08 - |
2TRFE..TGN121..5F..H;2TRFE..TGN126..6FC..L;1GDFTV..GUN126..6F..TH;2GDFTV..GUN125..
1GDFTV..GUN126..6FC..TH
6F..S..GEN;2GDFTV..GUN125..(H,L)..GEN;2TRFE..TGN126..THP..5F..(GCC,GEN,SA);2TRFE..
TGN121,126..THP..6FC..(ARL,GEN,SA);2GDFTV..GUN125..GHA,IDN,KEN,MA,PH,SA,TH,VN;1TRF
E,2TRFE..TGN120,121,136..LHD..THP..(L,S);1GDFTV..GUN126..DCRL..(GEN,GHA,KEN,MA,MMR
,PH,SA,VN);1GDFTV,2GDFTV..GUN120,121,122,13#..DCRL..(GEN,PH,SA,TH,VN)
TOYOTA STOP & START SYSTEM-WITHOUT
|
6733E0 |
| HILUX (SCB/XTR) | 2024.02 - 2024.12 |
2GDFTV..GUN125,135..KEN
DENSO
|
6723D0 |
| HILUX (DOUBLE CAB) | 2024.02 - 2024.12 |
1GDFTV,2GDFTV..GUN125,126..GHA,KEN
DENSO
|
6733D0 |
| HILUX (SCB/XTR) | 2024.02 - 2024.10 |
1GDFTV,2GDFTV..GUN122,125,126,13#..SA
DENSO
|
6723D0 |
| HILUX (DOUBLE CAB) | 2024.02 - 2024.10 |
1GDFTV,2GDFTV..GUN122,125,126,13#..SAP..DCRL
DENSO
|
6733D0 |
| HILUX (DOUBLE CAB) | 2023.08 - 2024.09 |
1GDFTV..GUN126..IND
|
6733D0 |
| HILUX (SCB/XTR) | 2023.08 - 2024.08 |
2GDFTV..GUN125..MA
|
6723D0 |
| HILUX (DOUBLE CAB) | 2023.08 - 2024.08 |
1GDFTV,2GDFTV..GUN125,126..CAMP,MAP,MMRP
|
6733D0 |
| HILUX (SCB/XTR) | 2023.08 - 2024.07 |
1TRFE,2TRFE..TGN11#,12#..ARL,GCC,GEN,IDN,TH;1GDFTV,2GDFTV..GUN112,12#,135..GEN,IDN
,PH,TH
|
6723D0 |
| HILUX (DOUBLE CAB) | 2023.08 - 2024.07 |
2TRFE..TGN121..5F..H;2TRFE..TGN126..6FC..L;2TRFE..TGN126..5F..(GCC,GEN);1GDFTV..GU
1GDFTV..GUN126..6FC..TH
N126..6F..(GEN,PH,TH);1TRFE,2TRFE..TGN120,121..THP..(L,S);1GDFTV..GUN126..THP..6FC
..DCRL..(GEN,PH,VN);2GDFTV..GUN125..THP..6F..S..(GEN,IDN,SA,TH,VN);1GDFTV,2GDFTV,2
TRFE..GUN120,121,122,135,TGN136..GEN,PH,TH,VN;2GDFTV,2TRFE..GUN125,TGN126..THP..(6
F,6FC)..(H,L)..(GEN,IDN,PH,SA)
TOYOTA STOP & START SYSTEM-WITHOUT
|
6733D0 |
| HILUX (SCB/XTR) | 2023.08 - |
1GDFTV,2GDFTV,2TR..GUN122,126,TGN121..PKN
|
6723D0 |
| HILUX (DOUBLE CAB) | 2023.08 - |
1GDFTV..GUN126..PKN
|
6733D0 |
| VIOS/YARIS | 2023.03 - |
1NRFE,2NRFE..NSP150,151..GCC,GEN,MA,VN
|
149340 |
| HILUX (SCB/XTR) | 2023.01 - 2024.03 |
2GDFTV..GUN125,135..KEN
DENSO
|
6723C0 |
| HILUX (DOUBLE CAB) | 2023.01 - 2024.03 |
1GDFTV,2GDFTV..GUN125,126..GHA,KEN
DENSO
|
6733C0 |
| HILUX (SCB/XTR) | 2023.01 - 2024.01 |
1GDFTV,2GDFTV..GUN122,125,126,13#..SA
DENSO
|
6723C0 |
| HILUX (DOUBLE CAB) | 2023.01 - 2024.01 |
1GDFTV,2GDFTV..GUN122,125,126,13#..SA
DENSO
|
6733C0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2023.09 |
1GDFTV..GUN126..IND,MMR
|
6733C0 |
| HILUX (SCB/XTR) | 2022.08 - 2023.08 |
2GDFTV..GUN125..MA
|
6723C0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2023.08 |
1GDFTV,2GDFTV..GUN125,126..MA
|
6733C0 |
| HILUX (SCB/XTR) | 2022.08 - 2023.07 |
2GDFTV..GUN125..6F..(GEN,IDN,TH);1TRFE,2TRFE..TGN11#,12#..ARL,GCC,GEN,IDN,TH;1GDFT
V,2GDFTV..GUN112,120,121,122,126,135..GEN,IDN,PH,TH
|
6723C0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2023.07 |
2TRFE..TGN121..5F..H;2TRFE..TGN126..6FC..L;2TRFE..TGN126..5F..(GCC,GEN);1GDFTV..GU
1GDFTV..GUN126..6FC..TH
N126..6F..(GEN,PH,TH);1GDFTV..GUN126..6FC..(GEN,PH,VN);1TRFE,2TRFE..TGN120,121..TH
P..(L,S);2GDFTV..GUN125..6F..S..(GEN,IDN,TH,VN);2GDFTV,2TRFE..GUN125,TGN126..(6F,6
FC)..(H,L)..(GEN,IDN,PH);1GDFTV,2GDFTV,2TRFE..GUN120,121,122,135,TGN136..GEN,PH,TH
,VN
TOYOTA STOP & START SYSTEM-WITHOUT
|
6733C0 |
| HILUX (SCB/XTR) | 2022.08 - |
1GDFTV,2GDFTV,2TRFE..GUN122,126,TGN121..PKN
|
6723C0 |
| HILUX (DOUBLE CAB) | 2022.08 - |
1GDFTV..GUN126..PKN
|
6733C0 |
| HILUX (SCB/XTR) | 2021.09 - 2023.03 |
1GDFTV,2GDFTV..GUN122,125,126,13#..KEN,SA
DENSO
|
6723B0 |
| HILUX (DOUBLE CAB) | 2021.09 - 2023.03 |
1GDFTV,2GDFTV..GUN122,125,126,13#..GHA,KEN,SA
DENSO
|
6733B0 |
| HILUX (SCB/XTR) | 2021.08 - 2023.01 |
1GDFTV,2GDFTV,2TRFE..GUN122,126,TGN121..PKN
|
6723B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2023.01 |
1GDFTV..GUN126..MMR,PKN
|
6733B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2022.09 |
1GDFTV..GUN126..IND
|
6733B0 |
| HILUX (SCB/XTR) | 2021.08 - 2022.08 |
2GDFTV..GUN125..MA
|
6723B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2022.08 |
1GDFTV,2GDFTV..GUN125,126..MA
|
6733B0 |
| HILUX (SCB/XTR) | 2021.08 - 2022.07 |
2GDFTV..GUN125..6F..(GEN,IDN,TH);1TRFE,2TRFE..TGN11#,12#..ARL,GCC,GEN,IDN,TH;1GDFT
V,2GDFTV..GUN112,120,121,122,126,135..GEN,IDN,PH,TH
|
6723B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2022.07 |
2TRFE..TGN121..5F..H;2TRFE..TGN126..6FC..L;2GDFTV..GUN135..H..GEN;2TRFE..TGN121..T
1GDFTV..GUN126..6FC..TH
HP..(L,S);2TRFE..TGN126..5F..(GCC,GEN);1GDFTV..GUN126..6F..(GEN,PH,TH);1GDFTV..GUN
126..6FC..(GEN,PH,VN);2GDFTV..GUN125..6F..S..(GEN,IDN,TH,VN);2GDFTV,1TRFE..GUN135,
TGN120..GCC,PH,TH,VN;1GDFTV,2GDFTV,2TRFE..GUN120,121,122,TGN136..GEN,PH,TH;2GDFTV,
2TRFE..GUN125,TGN126..(6F,6FC)..(H,L)..(GEN,IDN,PH)
TOYOTA STOP & START SYSTEM-WITHOUT
|
6733B0 |
| HILUX | 2020.06 - 2023.01 |
2TRFE..TGN121..5F..H;2TRFE..TGN126..6FC..L;2GDFTV..GUN135..H..GEN;1GDFTV..GUN126..
GEN,PH,VN;1GDFTV..GUN126..TD..6F..TH;2TRFE..TGN126..5F..(GCC,GEN);2GDFTV..GUN135..
KEN,PH,SA,TH,VN;2GDFTV..GUN125..6FC..(IDN,MA,SA);2GDFTV,2TRFE..GUN125,TGN126..TD..
6FC..(H,L)..GEN;2GDFTV..GUN125..6F..(GEN,IDN,KEN,MA,PH,SA,TH,VN);1GDFTV,2GDFTV..GU
N112,120,122,123,136..GEN,IDN,PH,SA,TH;1TRFE,2TRFE..TGN11#,120,121,136..(L,S)..(AR
L,GCC,GEN,IDN,TH);1GDFTV..GUN126..(KD,MD,MMD,SD,SS,SX,TS,TX)..(KEN,MA,MMR,SA,TH)
|
6723A0 |
| HILUX | 2020.06 - 2022.01 |
1GDFTV,2GDFTV,2TRFE..GUN122,126,TGN121..PKN
|
6723A0 |
| HILUX | 2020.06 - 2021.11 |
1GDFTV,2GDFTV..GUN125,126..GHA
|
6723A0 |
| HILUX | 2020.06 - 2021.08 |
1GDFTV..GUN126..TD..6FC..TH
TOYOTA STOP & START SYSTEM-WITHOUT
|
6723A0 |
| YARIS | 2017.09 - 2023.02 |
1NRFE..NSP150..LHD..(GCC,GEN);2NRFE,3NRFE..NSP151,152..(GCC,GEN,MA,TH,VN)..(A,B)
|
113320 |
| YARIS | 2017.09 - 2022.07 |
2NRFE..NSP151..PH,SA;1NRFE..NSP150..CVT..PH
|
113320 |
| YARIS | 2017.09 - 2021.08 |
1NRFE..NSP150..RHD;1NRFE..NSP150..5F..PH
|
113320 |
| YARIS/VIOS/LIMO | 2017.08 - 2022.07 |
1NRFE..NSP150..CVT..G..A;2NRFE..NSP151..LHD..GEN..A;2NRFE..NSP151..RHD..(GEN,MA);1
NRFE..NSP150..5F..GCC..R..A;1NRFE..NSP150..CVT..GCC..(D,R)..A;2NRFE..NSP151..(GCC,
PH,TH,VN)..(A,D,E);1NRFE,3NRFE..NSP150,152..(GEN,PH,TH,VN)..(D,R)..(A,D,E)
|
149330 |
| YARIS/VIOS/LIMO | 2017.08 - 2021.08 |
1NRFE..NSP150..5F..G..A;1NRFE..NSP150..5F..GCC..D..A
|
149330 |
| HILUX | 2016.01 - 2021.02 |
1GDFTV,2GDFTV..GUN122,125,126,13#..KEN,SA
DENSO
|
672390 |
| HILUX | 2015.05 - 2021.05 |
2GDFTV..GUN135..H;2TRFE..TGN121..5F..M;2GDFTV..GUN135..L..MA;2TRFE..TGN126..6FC..L
;1GDFTV..GUN126..6F..H..TH;2TRFE..TGN126..(TDC,TSC)..5F;2TRFE..TGN121..(TDC,TSC,TX
T)..(L,S,X);2GDFTV..GUN125..RHD..TDC..6FC..(L,M,X);1GDFTV..GUN126..TDC..(ARL,GEN,L
A,PH,TAIW,VN);2GDFTV..GUN125..TDC..6F..(ARL,GEN,IDN,LA,PH,TH,VN);2GDFTV,2TRFE..GUN
125,TGN126..LHD..TDC..6FC..(GEN,LA);2GDFTV,1TRFE,2TRFE..GUN135,TGN11#,120..(TDC,TS
C,TXT)..(ARL,GCC,IDN,LA,PH,TH,VN);1GDFTV,2GDFTV..GUN125,126..(MDC,MSC,PDC,PSC,TSC,
TXT)..(ARL,GEN,IDN,LA,MA,PKN,TH);2GDFTV,1KDFTV,2KDFTV..GUN112,120,KUN12#,135..(PDC
,PSC,SDC,SSC,SXT,TDC,TSC,TXT)..(GEN,IDN,LA,PKN,SA,TH,VN);1GDFTV,2GDFTV,1KDFTV,2KDF
TV,2TRFE..GUN122,123,136,KUN112,136,TGN136..(PSC,TDC,TSC,TXT)..(ARL,GEN,IDN,LA,PH,
PKN,TH)
|
672390 |
| HILUX | 2015.05 - 2017.08 |
2TRFE..TGN126..6FC..M..GCC;2GDFTV,2TRFE..GUN135,TGN121..(6F,6FC)..(L,M)..(GCC,GEN)
|
672390 |
| YARIS | 2013.10 - 2017.08 |
1NRFE,2NRFE,3NRFE..NSP15#..GCC,GEN,PH,TH,VN
|
113320 |
| YARIS | 2013.10 - 2016.09 |
1NZFE..NCP150..C
|
113320 |
| YARIS | 2013.10 - 2016.06 |
1NZFE,2NZFE..NCP15#..GCC,GEN,PH,VN
|
113320 |
| YARIS/VIOS/LIMO | 2013.04 - 2018.12 |
2NRFE..NSP151..MA
|
149330 |
| YARIS/VIOS/LIMO | 2013.04 - 2018.07 |
1NRFE,2NRFE..NSP150,151..VN
|
149330 |
| YARIS/VIOS/LIMO | 2013.04 - 2018.06 |
1NRFE,2NRFE..NSP150,151..PH
|
149330 |
| YARIS/VIOS/LIMO | 2013.04 - 2017.12 |
1NRFE,2NRFE..NSP150,151..GCC..B
|
149330 |
| YARIS/VIOS/LIMO | 2013.04 - 2017.09 |
1NRFE,2NRFE..NSP150,151..GEN
|
149330 |
| YARIS/VIOS/LIMO | 2013.04 - 2016.09 |
1NZFE,2NZFE..NCP15#..C
|
149330 |
| YARIS/VIOS/LIMO | 2013.04 - 2016.08 |
1NZFE,2NZFE..NCP15#..MA,VN
|
149330 |
| YARIS/VIOS/LIMO | 2013.04 - 2016.06 |
1NZFE,2NZFE..NCP15#..PH
|
149330 |
| YARIS/VIOS/LIMO | 2013.04 - 2016.03 |
1NZFE,2NZFE..NCP15#..(GCC,GEN,TH)..B
|
149330 |
| YARIS/VIOS/LIMO | 2013.04 - 2015.06 |
1NZFE..NCP150..IDN..B
|
149330 |
| YARIS/VIOS/LIMO | 2013.04 - |
2NRFE..NSP151..TH..B
|
149330 |
Related Parts
| Part Number | Reference |
|---|---|
| 27039-0C190 | COVER, ALTERNATOR REAR END |
| 27039-0M100 | COVER, ALTERNATOR REAR END |
| 27039-0Y180 | COVER, ALTERNATOR REAR END |
| 27039-0Y200 | COVER, ALTERNATOR REAR END |
| 27039-0Y260 | COVER, ALTERNATOR REAR END |
| 27060-0M090 | ALTERNATOR ASSY |
| 27060-0M110 | ALTERNATOR ASSY |
| 27060-0Y200 | ALTERNATOR ASSY |
| 27060-0Y300 | ALTERNATOR ASSY |
| 27060-0Y310 | ALTERNATOR ASSY |
| 27060-0Y320 | ALTERNATOR ASSY |
| 27060-0Y330 | ALTERNATOR ASSY |
Toyota part number 27330-0M100 corresponds to ROTOR ASSY, ALTERNATOR. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
