Toyota 23209-79186 INJECTOR ASSY, FUEL
23209-79186
Part overview:
OEM reference 23209-79186 for INJECTOR ASSY, FUEL.
This page currently lists 6 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 23250 |
| Manufacturer Part Number | 23209-79186 |
| Part Description | INJECTOR ASSY, FUEL |
| Condition | New |
| Quantity Per Vehicle | 4 |
| SKU | 23209-79186 |
| Catalog | 711350 |
| PNC | 23250 |
| PNC Group | INJECTOR ASSY, FUEL |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| HIACE | 2012.05 - 2014.02 |
2TRFE..TRH201,203,213,22#..4FC
*272
|
711350 |
| HIACE | 2012.05 - 2013.12 |
2TRFE..TRH223..LHD..STD..GEN
2TRFE..TRH201,22#..4FC..ARL
2TRFE..TRH203,213,223..RHD..GEN
VIETNAM SPEC,*272
LPG CONVERSION PACKAGE,*272
PAKISTAN SPEC,*272
|
711350 |
| HIACE | 2012.03 - 2013.12 |
2TRFE..TRH221..SP..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH201,203,213..LHD..(S
MRF,SRF)..STD..GEN
NIGERIA SPEC,*272
|
711350 |
| HIACE | 2010.05 - 2014.02 |
2TRFE..TRH201,203,213,22#..5F..(GCC,SA)
*272
|
711350 |
| HIACE | 2010.05 - 2013.12 |
2TRFE..TRH223..LHD..5F..GEN;2TRFE..TRH201,203,213..LHD..(SMRF,SRF)..STD..GEN
2TRFE..TRH221..SP..GEN;2TRFE..TRH223..LHD..5F..GEN;2TRFE..TRH201,203,213..LHD..(SM
RF,SRF)..(03S,12S,16S)..GEN
CENTRAL AMERICA(4COUNTRY) SPEC,*272
VENEZUERA SPEC,*272
|
711350 |
| HIACE | 2010.05 - 2010.08 |
2TRFE..TRH213..GL..GEN
VENEZUERA SPEC,*272
|
711350 |
Related Parts
| Part Number | Reference |
|---|---|
| 22030-0C020 | BODY ASSY, THROTTLE W/MOTOR |
| 22030-75010 | BODY ASSY, THROTTLE W/MOTOR |
| 22030-75020 | BODY ASSY, THROTTLE W/MOTOR |
| 22271-0C021 | GASKET, THROTTLE BODY |
| 22271-37010 | GASKET, THROTTLE BODY |
| 23209-09045 | INJECTOR ASSY, FUEL |
| 23209-09055 | INJECTOR ASSY, FUEL |
| 23209-79155 | INJECTOR ASSY, FUEL |
| 23209-79205 | INJECTOR ASSY, FUEL |
| 23270-75010 | DAMPER ASSY, FUEL PRESSURE PULSATION |
| 23271-75190 | HOSE, FUEL |
| 23271-75200 | HOSE, FUEL |
Toyota part number 23209-79186 corresponds to INJECTOR ASSY, FUEL. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
