Toyota 22030-25010 BODY ASSY, THROTTLE W/MOTOR
22030-25010
Part overview:
OEM reference 22030-25010 for BODY ASSY, THROTTLE W/MOTOR.
This page currently lists 21 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 22030 |
| Manufacturer Part Number | 22030-25010 |
| Part Description | BODY ASSY, THROTTLE W/MOTOR |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 22030-25010 |
| Catalog | 2834A0 |
| PNC | 22030 |
| PNC Group | BODY ASSY, THROTTLE W/MOTOR |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| LEXUS NX SERIES(JPP) | 2024.04 - 2025.06 |
A25AFKS..AAZA2#
|
527420 |
| RAV4 (JPP) | 2023.10 - |
A25AFKS..AXAA5#..JPP
|
662250 |
| RAV4 (JPP) | 2023.10 - |
A25AFKS..AXAA5#
|
662450 |
| RAV4 (NAP) | 2022.11 - |
A25AFKS..AXAA54;A25AFKS..AXAA52..G,X;A25AFKS..AXAA52..M..USA
*584
|
665430 |
| RAV4 (JPP) | 2022.10 - 2023.10 |
A25AFKS..AXAA5#..JPP
|
662250 |
| RAV4 (JPP) | 2022.10 - 2023.10 |
A25AFKS..AXAA5#
|
662450 |
| LEXUS NX SERIES(JPP) | 2021.11 - 2024.03 |
A25AFKS..AAZA2#
|
527420 |
| CAMRY/HYBRID (NAP) | 2020.10 - |
A25AFKS..AXVA70
*132
|
2834A0 |
| RAV4 (NAP) | 2020.09 - 2022.11 |
A25AFKS..AXAA54;A25AFKS..AXAA52..G,X;A25AFKS..AXAA52..M..USA
*584
|
665430 |
| RAV4 (NAP) | 2020.09 - |
A25AFKS..AXAA52..M..CND
*584
|
665430 |
| RAV4 (JPP) | 2020.08 - 2022.10 |
A25AFKS..AXAA52..GCC;A25AFKS..AXAA54..LHD..V;A25AFKS..AXAA54..(M,V,X)..ARL;A25AFKS
..AXAA52..LHD..(G,M)..GEN;A25AFKS..AXAA54..(G,M,X)..(GCC,GEN,SA)
|
662250 |
| RAV4 (JPP) | 2020.08 - 2022.10 |
A25AFKS..AXAA5#
|
662450 |
| RAV4 (JPP) | 2020.08 - 2022.03 |
A25AFKS..AXAA54..RUS
|
662250 |
| RAV4 (JPP) | 2020.08 - 2021.11 |
A25AFKS..AXAA52..RHD;A25AFKS..AXAA52..X..GEN;A25AFKS..AXAA54..G..ARL;A25AFKS..AXAA
54..RHD..V..GEN
|
662250 |
| RAV4 (NAP) | 2018.12 - 2020.09 |
A25AFKS..AXAA5#
*584
|
665430 |
| RAV4 (JPP) | 2018.11 - 2020.09 |
A25AFKS..AXAA54..RUS
|
662250 |
| RAV4 (JPP) | 2018.11 - 2020.07 |
A25AFKS..AXAA5#..ARL,GCC,GEN,SA
|
662250 |
| RAV4 (JPP) | 2018.11 - 2020.07 |
A25AFKS..AXAA5#
|
662450 |
| RAV4 (JPP) | 2018.11 - 2020.04 |
A25AFKS..AXAA54..EUR
|
662250 |
| CAMRY/HYBRID (NAP) | 2017.06 - 2020.10 |
A25AFKS..AXVA70
*132
|
2834A0 |
| CAMRY (JPP) | 2017.03 - 2018.11 |
A25AFKS..AXVA70
|
2844A0 |
Related Parts
| Part Number | Reference |
|---|---|
| 17703-47010 | CAP SUB-ASSY, DUST |
| 22030-0P060 | BODY ASSY, THROTTLE W/MOTOR |
| 22030-F0010 | BODY ASSY, THROTTLE W/MOTOR |
| 22030-F0020 | BODY ASSY, THROTTLE W/MOTOR |
| 22271-0P020 | GASKET, THROTTLE BODY |
| 22271-25010 | GASKET, THROTTLE BODY |
| 22271-F0010 | GASKET, THROTTLE BODY |
| 22271-F0020 | GASKET, THROTTLE BODY |
| 23101-0P010 | PUMP ASSY, FUEL |
| 23101-25040 | PUMP ASSY, FUEL |
| 23101-F0010 | PUMP ASSY, FUEL |
| 23191-25050 | FLANGE, FUEL PUMP |
Toyota part number 22030-25010 corresponds to BODY ASSY, THROTTLE W/MOTOR. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
