Toyota 12111-20060 PAN SUB-ASSY, OIL
12111-20060
Part overview:
OEM reference 12111-20060 for PAN SUB-ASSY, OIL.
This page currently lists 13 fitment groups.
Use the catalog link and vehicle fitment table below to confirm application details.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
NeoZeroAuto supplies Toyota and Lexus replacement parts with fitment-reference support.
- OEM-quality replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Send the part number and quantity to receive a quotation.
Contact Us for Quote
Request a Quote
Chat on WhatsApp
Email: [email protected]
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 12101 |
| Manufacturer Part Number | 12111-20060 |
| Part Description | PAN SUB-ASSY, OIL |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 12111-20060 |
| Catalog | 283470 |
| PNC | 12101 |
| PNC Group | PAN SUB-ASSY, OIL |
Vehicle Fitment
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| HIGHLANDER (JPP) | 2007.08 - |
3MZFE..MHU48
|
522420 |
| SOLARA | 2006.05 - 2008.08 |
3MZFE..MCV31..CP
(J)
|
286420 |
| SOLARA | 2006.05 - |
3MZFE..MCV31..CVT
(J)
|
286420 |
| LEXUS RX400H | 2005.03 - 2008.12 |
3MZFE..MHU3#
|
524410 |
| HIGHLANDER HV | 2005.03 - |
3MZFE..MHU2#
|
525410 |
| CAMRY (NAP) | 2004.06 - |
1MZFE,3MZFE..MCV3#..NAP
(J)
|
283470 |
| CAMRY (JPP) | 2004.06 - |
1MZFE,3MZFE..MCV3#..JPP
|
284470 |
| LEXUS RX330/350(NAP) | 2003.09 - |
3MZFE..MCU3#..NAP
(J)
|
523410 |
| HIGHLANDER | 2003.08 - |
3MZFE..MCU2#
|
522410 |
| SOLARA | 2003.07 - 2006.05 |
3MZFE..MCV31
(J)
|
286420 |
| LEXUS RX330/350(JPP) | 2003.02 - |
3MZFE..MCU3#..JPP
|
521420 |
| CAMRY (JPP) | 2003.01 - 2004.06 |
3MZFE..MCV31..JPP;1MZFE..MCV30..JPP..(LE,XLE)
|
284470 |
| CAMRY (JPP) | 2003.01 - 2003.07 |
1MZFE..MCV30..JPP..SE
|
284470 |
Related Parts
| Part Number | Reference |
|---|---|
| 11271-20010 | COVER, CYLIVDER BLOCK SIDE |
| 11361-0H020 | COVER, FLYWHEEL HOUSING UNDER |
| 11361-28010 | COVER, FLYWHEEL HOUSING UNDER |
| 11401-09102 | BLOCK SUB-ASSY, CYLINDER |
| 11401-09210 | BLOCK SUB-ASSY, CYLINDER |
| 11401-09260 | BLOCK SUB-ASSY, CYLINDER |
| 11401-29516 | BLOCK SUB-ASSY, CYLINDER |
| 11401-29556 | BLOCK SUB-ASSY, CYLINDER |
| 11410-09050 | BLOCK SUB-ASSY, CYLINDER |
| 11410-29105 | BLOCK SUB-ASSY, CYLINDER |
| 11410-29185 | BLOCK SUB-ASSY, CYLINDER |
| 11410-29325 | BLOCK SUB-ASSY, CYLINDER |
Toyota part number 12111-20060 corresponds to PAN SUB-ASSY, OIL. Use the fitment table, catalog reference, and PNC group information above to confirm compatibility.
For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
