04947-0K120 FITTING KIT, DISC BRAKE, FRONT
Toyota EPC Name: FITTING KIT, DISC BRAKE, FRONT
04947-0K120
Quick Buying Check
Fitment
37 EPC group(s)
Use VIN verification before ordering.
Reference
04947
FITTING KIT, DISC BRAKE, FRONT
Supply
Manual quote
Price, MOQ, and lead time confirmed before shipment.
Toyota & Lexus Parts Specialist
Based in China | Wholesale / B2B
- Fitment-referenced replacement parts
- Wholesale supply for distributors
- Worldwide shipping support
Request Price & Fitment Confirmation
Send part number, quantity, destination country, and VIN if available.
Email: [email protected]
Send detailed request
Fitment Reference
Toyota and Lexus part applications can vary by market, production date, chassis code, engine, trim, and catalog. Always verify part number 04947-0K120, PNC, vehicle application, and VIN before ordering.
| Model Name | Fr-To | Model Description | Catalog |
|---|---|---|---|
| HILUX (SCB/XTR) | 2024.11 - |
LAN125;GUN125..L..KEN
GUN125..LHD..L..SA
TYPE B:REFER ILLUST.
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6723E0 |
| HILUX (DOUBLE CAB) | 2024.11 - |
TGN126..SP..L;LAN125,TGN136..LHD..SA
TGN126..SAP..L;LAN125,TGN136..LHD..SA
TYPE B:REFER ILLUST.
|
6733E0 |
| HILUX (SCB/XTR) | 2024.08 - |
GUN125,135..RHD..SCB..L..(GEN,SA)
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6723E0 |
| HILUX (DOUBLE CAB) | 2024.08 - |
GUN125..LHD..L..GEN
GUN125..RHD..6F..L..GEN;GUN125..LHD..(GAP,SP)..L
TGN126..L..GEN
GUN125..RHD..6F..L..GEN;GUN125..LHD..(GHAP,SAP)..L
ASIA COLD COUNTRY SPEC&VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER IL
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
LUST.
|
6733E0 |
| HILUX (SCB/XTR) | 2024.02 - 2024.12 |
GUN125..L..KEN
TYPE B:REFER ILLUST.
|
6723D0 |
| HILUX (SCB/XTR) | 2024.02 - 2024.10 |
LAN125
GUN125..LHD..L..SA
TYPE B:REFER ILLUST.
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6723D0 |
| HILUX (DOUBLE CAB) | 2024.02 - 2024.10 |
TGN126..SAP..L;LAN125,TGN136..LHD..SA
TYPE B:REFER ILLUST.
|
6733D0 |
| HILUX (DOUBLE CAB) | 2023.08 - 2024.12 |
GUN125..L..GHA
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6733D0 |
| HILUX (SCB/XTR) | 2023.08 - 2024.10 |
GUN125,135..RHD..SCB..L..SA
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6723D0 |
| HILUX (DOUBLE CAB) | 2023.08 - 2024.10 |
GUN125..LHD..SAP..L
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6733D0 |
| HILUX (SCB/XTR) | 2023.08 - 2024.07 |
GUN125..RHD..GEN
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6723D0 |
| HILUX (DOUBLE CAB) | 2023.08 - 2024.07 |
GUN125..LHD..L..GEN
GUN125..RHD..6F..L..GEN
TGN126..L..GEN
ASIA COLD COUNTRY SPEC&VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER IL
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
LUST.
|
6733D0 |
| HILUX (SCB/XTR) | 2023.01 - 2024.01 |
LAN125;GUN125..L..KEN
TYPE B:REFER ILLUST.
|
6723C0 |
| HILUX (DOUBLE CAB) | 2023.01 - 2024.01 |
TGN126..L..SA;LAN125,TGN136..LHD..SA
TYPE B:REFER ILLUST.
|
6733C0 |
| HILUX (SCB/XTR) | 2022.08 - 2024.01 |
GUN125,135..RHD..SCB..6F..L..(GEN,SA)
GUN125..LHD..L..(GEN,SA)
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6723C0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2024.01 |
GUN125..6F..L..GEN;GUN125..LHD..L..SA
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6733C0 |
| HILUX (DOUBLE CAB) | 2022.08 - 2023.07 |
TGN126..L..GEN
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6733C0 |
| HILUX (SCB/XTR) | 2021.09 - 2023.03 |
LAN125;GUN125..L..KEN;GUN125..LHD..SA..IV3
TYPE B:REFER ILLUST.
|
6723B0 |
| HILUX (DOUBLE CAB) | 2021.09 - 2023.01 |
LAN125;TGN126,136..L..SA
TYPE B:REFER ILLUST.
|
6733B0 |
| HILUX (SCB/XTR) | 2021.08 - 2023.01 |
GUN125,135..RHD..SCB..L..SA
GUN125..LHD..L..SA..CBU
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6723B0 |
| HILUX (SCB/XTR) | 2021.08 - 2022.07 |
GUN125..RHD..6F..L..GEN
GUN125..LHD..L..GEN
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6723B0 |
| HILUX (DOUBLE CAB) | 2021.08 - 2022.07 |
GUN125..6F..L..GEN
TGN126..L..GEN
VSC-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
6733B0 |
| HILUX | 2020.09 - 2021.11 |
GUN125..KS..L;LAN125,TGN126,136..LHD..SA
TYPE B:REFER ILLUST.
|
6723A0 |
| HILUX | 2020.06 - 2021.09 |
GUN135..SS..L;GUN125..(SS,TD,TS)..6F..L..(GEN,SA)
VEHICLE STABILITY CONT-WITHOUT&TIRE & DISC WHEEL-205R16C, STEEL,TYPE B:REFER ILLUS
T.
|
6723A0 |
| HILUX | 2020.06 - 2021.08 |
TGN126..L..GEN
TIRE & DISC WHEEL-205R16C, STEEL,TYPE B:REFER ILLUST.
|
6723A0 |
| HILUX | 2019.05 - 2020.05 |
TGN126..S..GEN
GUN125..LHD..TDC..S..GEN
OCEANIA GENERAL SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C S
CAMBODIA SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TY
TEEL,TYPE B:REFER ILLUST.
PE B:REFER ILLUST.
|
672390 |
| HILUX | 2019.04 - 2019.12 |
GUN125..TSC..X..GEN
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
672390 |
| HILUX | 2019.04 - 2019.05 |
TGN126..S..GEN
OCEANIA GENERAL SPEC&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
672390 |
| HILUX | 2018.08 - 2019.04 |
TGN126..6FC..M..GCC
SUDAN SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE
B:REFER ILLUST.
|
672390 |
| HILUX | 2017.08 - 2020.05 |
TGN126..TDC..L..GCC;GUN125..TDC..6F..L..GCC
GUN125..LHD..TDC..S..GEN
TGN126..TSC..S;GUN125,TGN126..TDC..MTM..L..GCC
GUN125..TDC..6F..L..GCC
TGN126..TSC..S;TGN126..L..GCC..CBU;GUN125..TDC..6F..L..GCC
EGYPT SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE
VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILL
SUDAN SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE
AFRICA SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE
SYRIA SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE
ASIA COLD COUNTRY SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C
ASEAN GENERAL SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STE
OCEANIA GENERAL SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C S
B:REFER ILLUST.
UST.
STEEL,TYPE B:REFER ILLUST.
EL,TYPE B:REFER ILLUST.
TEEL,TYPE B:REFER ILLUST.
|
672390 |
| HILUX | 2017.08 - 2019.04 |
TGN126..M..GCC;GUN125..6F..M..GCC
GUN125,TGN126..MTM..M..GCC
EGYPT SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE
SUDAN SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE
AFRICA SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE
SYRIA SPEC&VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE
B:REFER ILLUST.
|
672390 |
| HILUX | 2016.10 - 2020.09 |
GUN125..LHD..SSC..S;GUN125,135..LHD..SDC..X
VEHICLE STABILITY CONTROL-WITHOUT&TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILL
UST.
|
672390 |
| HILUX | 2016.01 - 2016.09 |
KUN25
TYPE D:REFER ILLUST.
|
672380 |
| HILUX | 2015.05 - 2021.02 |
GUN125..LHD..SDC..S;GUN125..LHD..SSC..X;GUN125..LHD..L..GEN;LAN125,TGN126..5F..SA;
KUN125..LHD..(SDC,SSC)..S;TGN126..6FC..(L,S)..(GEN,SA);GUN126,135..RHD..X..(KEN,SA
,TH);GUN125,KUN125..TSC..(L,M,S)..GEN;KUN125..(SDC,TDC)..(L,X)..(GCC,GEN,SA);GUN12
5..RHD..(KDC,KSC,MSC,SDC,SSC,TDC)..(L,X)..(GEN,KEN,MA,SA)
TYPE B:REFER ILLUST.
|
672390 |
| HILUX | 2015.05 - 2020.05 |
TGN126..5F..L..GEN;GUN125,KUN125..TXT..M;KUN125..LHD..TDC..S..GEN;GUN125,KUN125..R
HD..TDC..M..GEN
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
672390 |
| HILUX | 2015.05 - 2019.05 |
TGN126..S..GEN
TIRE & DISC WHEEL-205R16C STEEL,TYPE B:REFER ILLUST.
|
672390 |
| HILUX | 2015.05 - 2017.08 |
GUN135..GEN;GUN125,TGN126..(L,S)..GCC
TYPE B:REFER ILLUST.
|
672390 |
Same PNC 04947 Part Numbers
04947-0K010
FITTING KIT, DISC BRAKE, FRONT
04947-0K020
FITTING KIT, DISC BRAKE, FRONT
04947-0K040
FITTING KIT, DISC BRAKE, FRONT
04947-0K050
FITTING KIT, DISC BRAKE, FRONT
04947-0K070
FITTING KIT, DISC BRAKE, FRONT
04947-0K080
FITTING KIT, DISC BRAKE, FRONT
04947-35050
FITTING KIT, DISC BRAKE, FRONT
04947-60080
FITTING KIT, DISC BRAKE, FRONT
04947-71010
FITTING KIT, DISC BRAKE, FRONT
04473-WC001
FITTING KIT, DISC BRAKE, FRONT
04947-02010
FITTING KIT, DISC BRAKE, FRONT
04947-02020
FITTING KIT, DISC BRAKE, FRONT
View more PNC 04947 part numbers
FAQ
What is 04947-0K120?
04947-0K120 is a Toyota/Lexus reference part number for FITTING KIT, DISC BRAKE, FRONT. Check PNC, fitment, catalog, and VIN before ordering.
How do I check if 04947-0K120 fits my vehicle?
Verify the OE number, PNC, vehicle catalog, production date, chassis, engine, trim, and VIN before ordering.
Is 049470K120 the same as 04947-0K120?
Yes. 049470K120 is a common search format without hyphens. Always verify the full OE number and fitment details.
Can NeoZeroAuto help verify 04947-0K120 by VIN?
Yes. Send the VIN, part number, quantity, and destination country for manual fitment reference support.
Related Parts
Technical Reference Details
Specifications
| Brand | NeoZeroAuto |
| Part Name Code | 04947 |
| Manufacturer Part Number | 04947-0K120 |
| Part Description | FITTING KIT, DISC BRAKE, FRONT |
| Condition | New |
| Quantity Per Vehicle | 1 |
| SKU | 04947-0K120 |
| Catalog | 672380 |
| PNC | 04947 |
| PNC Group | FITTING KIT, DISC BRAKE, FRONT |
OE Number Variants
This reference page covers part number 04947-0K120. OE and reference number variants include:
- 04947-0K120
- 049470K120
- 04947 0K120
What is 04947-0K120?
04947-0K120 is a Toyota/Lexus reference part number for FITTING KIT, DISC BRAKE, FRONT. In EPC data, it is listed as FITTING KIT, DISC BRAKE, FRONT under PNC 04947. Use the fitment table above to confirm catalog, production date, engine, chassis, and market application.
Toyota reference part number 04947-0K120 corresponds to FITTING KIT, DISC BRAKE, FRONT. Toyota EPC lists this part as FITTING KIT, DISC BRAKE, FRONT. For higher accuracy, verify by VIN, production date, market, and detailed vehicle configuration before ordering or quoting.
